SUR
CONNECTOR
Emboss Tape
0.8mm pitch/Disconnectable Insulation displacement connectors
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC (AWG #32)
0.2A AC, DC (AWG #36)
• Voltage rating: 30V DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 20m
Ω
max.
After environmental testing/ 40m
Ω
max.
• Insulation resistance: 100M
Ω
min.
• Withstanding voltage: 200V AC/minute
• Applicable wire: Conductor size/ AWG #32, #36
Conductor/ 7 strands,
tin-coated copper alloy
Insulation O.D./ 0.39mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
The world's first 0.8mm pitch wire-to-board
insulation displacement connector. Side
entry type is only 3.9mm depth and
1.75mm height after mounting on the PC
board, and top entry type is only 2.2mm
depth and 3.9mm height.
Compared to the conventional 1.0mm pitch
SSR connector, occupation space on the
board is reduced by 34% (side entry type).
• 3-point grip construction
• Super fine wires are applicable
• Shrouded header
• Twin U-slot insulation displacement section
Standards ––––––––––––––––––––––
1
Certified LR20812
0
Recognized E60389
Top entry type
2.25
2
±0.1
Side entry type
Header
outline
0.8
±0.05
0.5
±0.05
±0.1
0.7
±0.1
1.2
±0.1
3.9
0.3
1
±0.1
1.75
1.7
3.95
±0.1
±0.1
1.1
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. Dimensions above should serve as a guideline. Contact JST for details.
1
0.35
0.5
±0.05
0.8
±0.05
Header outline
0.7
±0.1
1.2
±0.1
±0.1
1.7
2.3
±0.1
SUR CONNECTOR
Socket
Circuits
2
3
4
5
Circuit No.1
6
8
1.65
1.25
1.45
10
12
14
15
16
17
20
22
0.8
A
B
0.8
2.9
1.7
Model No.
Dimensions (mm)
#32(Natural)
#36(Lemon yellow)
A
B
02SUR-32S
0.8
2.4
02SUR-36L
1.6
3.2
03SUR-32S
03SUR-36L
2.4
4.0
04SUR-32S
04SUR-36L
4.8
3.2
05SUR-32S
05SUR-36L
4.0
5.6
06SUR-32S
06SUR-36L
5.6
7.2
08SUR-32S
08SUR-36L
7.2
8.8
10SUR-32S
10SUR-36L
8.8
10.4
12SUR-32S
12SUR-36L
12.0
10.4
14SUR-32S
14SUR-36L
11.2
12.8
15SUR-32S
15SUR-36L
12.0
13.6
16SUR-32S
16SUR-36L
12.8
14.4
17SUR-32S
17SUR-36L
15.2
16.8
20SUR-32S
20SUR-36L
16.8
18.4
22SUR-32S
22SUR-36L
Material and Finish
Contact: Copper alloy, tin-plated
(reflow
treatment)
Housing: PA, UL94V-0
Q'ty / box
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
Shrouded header
Top entry type
B
2.7
Side entry type
B
A
Circuit No.1
0.8
2.7
1.75
H JST 5
RoHS compliance
Circuits
2
2
3
4
5
6
8
10
12
14
15
16
17
20
22
A
0.6
1
Dimensions (mm)
Model No.
A
B
Top entry type
Side entry type
BM02B-SURS-TF SM02B-SURS-TF
0.8
3.8
1.6
4.6
BM03B-SURS-TF SM03B-SURS-TF
2.4
5.4
BM04B-SURS-TF SM04B-SURS-TF
3.2
6.2
―
SM05B-SURS-TF
7.0
4.0
―
SM06B-SURS-TF
5.6
8.6
BM08B-SURS-TF SM08B-SURS-TF
7.2
10.2
BM10B-SURS-TF SM10B-SURS-TF
8.8
11.8
BM12B-SURS-TF SM12B-SURS-TF
10.4
13.4
―
SM14B-SURS-TF
11.2
14.2
BM15B-SURS-TF SM15B-SURS-TF
12.0
15.0
―
SM16B-SURS-TF
12.8
15.8
―
SM17B-SURS-TF
15.2
18.2
BM20B-SURS-TF SM20B-SURS-TF
16.8
19.8
―
SM22B-SURS-TF
Material and Finish
Q'ty / reel
Top entry type Side entry type
2,500
2,500
2,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
―
―
2,500
2,500
2,500
―
2,500
―
―
2,500
―
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: PA, UL94V-0, natural
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
1
0.45
1
0.2
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed-tape.
