MKE06Z64VLH4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> The embedded processor and controller> MKE06Z64VLH4

MKE06Z64VLH4: DescriptionIC mcu 32bit 64kb flash 64qfp; Categorysemiconductor The embedded processor and controller; File Size1MB，38 Pages; ManufacturerFREESCALE (NXP); Environmental Compliance

Download Datasheet Parametric Compare View All

MKE06Z64VLH4 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MKE06Z64VLH4	-	-	View	Buy Now

MKE06Z64VLH4 Overview

IC mcu 32bit 64kb flash 64qfp

MKE06Z64VLH4 Parametric

Parameter Name	Attribute value
Datasheets
MKE06Z Series
PCN Design/Specificati
MKE06/04Z128,64 Datasheet Update 16/Jun/2014
Standard Package	160
Category	Integrated Circuits (ICs)
Family	Embedded - Microcontrollers
Packaging	Tray
Core Process	ARM® Cortex®-M0+
Core Size	32-Bi
Speed	48MHz
Connectivity	CAN, I²C, SPI, UART/USART
Peripherals	LVD, WDT
Number of I/O	58
Program Memory Size	64KB (64K x 8)
Program Memory Type	FLASH
EEPROM Size	-
RAM Size	8K x 8
Voltage - Supply (Vcc/Vdd)	2.7 V ~ 5.5 V
Data Converters	A/D 16x12b, D/A 2x6b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 105°C
Package / Case	64-LQFP
Supplier Device Package	64-LQFP (10x10)
Dynamic Catalog	Kinetis KE06 Series

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Technical Data

Document Number MKE06P80M48SF0

Rev 3, 5/2014

KE06 Sub-Family Data Sheet

Supports the following:

MKE06Z64VLD4(R),

MKE06Z128VLD4(R),

MKE06Z64VQH4(R),

MKE06Z128VQH4(R),

MKE06Z64VLH4(R),

MKE06Z128VLH4(R),

MKE06Z64VLK4(R), and

MKE06Z128VLK4(R)

MKE06P80M48SF0

Key features

• Operating characteristics

– Voltage range: 2.7 to 5.5 V

– Flash write voltage range: 2.7 to 5.5 V

– Temperature range (ambient): -40 to 105°C

• Performance

– Up to 48 MHz ARM® Cortex-M0+ core

– Single cycle 32-bit x 32-bit multiplier

– Single cycle I/O access port

• Memories and memory interfaces

– Up to 128 KB flash

– Up to 16 KB RAM

• Clocks

– Oscillator (OSC) - supports 32.768 kHz crystal

or 4 MHz to 24 MHz crystal or ceramic

resonator; choice of low power or high gain

oscillators

– Internal clock source (ICS) - internal FLL with

internal or external reference, 37.5 kHz pre-

trimmed internal reference for 48 MHz system

clock

– Internal 1 kHz low-power oscillator (LPO)

• System peripherals

– Power management module (PMC) with three

power modes: Run, Wait, Stop

– Low-voltage detection (LVD) with reset or

interrupt, selectable trip points

– Watchdog with independent clock source

(WDOG)

– Programmable cyclic redundancy check module

(CRC)

– Serial wire debug interface (SWD)

– Aliased SRAM bitband region (BIT-BAND)

– Bit manipulation engine (BME)

• Security and integrity modules

– 80-bit unique identification (ID) number per chip

• Human-machine interface

– Up to 71 general-purpose input/output (GPIO)

– Two 32-bit keyboard interrupt modules (KBI)

– External interrupt (IRQ)

• Analog modules

– One up to 16-channel 12-bit SAR ADC,

operation in Stop mode, optional hardware

trigger (ADC)

– Two analog comparators containing a 6-bit

DAC and programmable reference input

(ACMP)

• Timers

– One 6-channel FlexTimer/PWM (FTM)

– Two 2-channel FlexTimer/PWM (FTM)

– One 2-channel periodic interrupt timer (PIT)

– One pulse width timer (PWT)

– One real-time clock (RTC)

Freescale reserves the right to change the detail specifications as may be

required to permit improvements in the design of its products.

Table of Contents

1 Ordering parts...........................................................................4

1.1 Determining valid orderable parts......................................4

2 Part identification......................................................................4

2.1 Description.........................................................................4

2.2 Format...............................................................................4

2.3 Fields.................................................................................4

2.4 Example............................................................................5

3 Parameter classification............................................................5

4 Ratings......................................................................................6

4.1 Thermal handling ratings...................................................6

4.2 Moisture handling ratings..................................................6

4.3 ESD handling ratings.........................................................6

4.4 Voltage and current operating ratings...............................7

5 General.....................................................................................7

5.1 Nonswitching electrical specifications...............................7

5.1.1

5.1.2

5.1.3

DC characteristics.................................................7

Supply current characteristics...............................14

EMC performance.................................................15

5.2.2

FTM module timing...............................................17

5.3 Thermal specifications.......................................................18

5.3.1

Thermal characteristics.........................................18

6 Peripheral operating requirements and behaviors....................20

6.1 Core modules....................................................................20

6.1.1

SWD electricals ....................................................20

6.2 External oscillator (OSC) and ICS characteristics.............21

6.3 NVM specifications............................................................23

6.4 Analog...............................................................................24

6.4.1

6.4.2

ADC characteristics...............................................24

Analog comparator (ACMP) electricals.................26

6.5 Communication interfaces.................................................27

6.5.1

6.5.2

SPI switching specifications..................................27

MSCAN.................................................................30

7 Dimensions...............................................................................30

7.1 Obtaining package dimensions.........................................30

8 Pinout........................................................................................31

8.1 Signal multiplexing and pin assignments...........................31

8.2 Device pin assignment......................................................33

9 Revision history.........................................................................36

5.2 Switching specifications.....................................................16

5.2.1

Control timing........................................................16

KE06 Sub-Family Data Sheet, Rev3, 5/2014.

Freescale Semiconductor, Inc.

MKE06Z64VLH4 Related Products

	MKE06Z64VLH4	MKE06Z128VLD4	MKE06Z128VLH4	MKE06Z128VQH4	MKE06Z128VLK4	MKE06Z64VLK4	MKE06Z64VLD4	MKE06Z64VQH4
Description	IC mcu 32bit 64kb flash 64qfp	arm microcontrollers - mcu kinetis E 32-bit mcu, arm cortex-M0+ cor	arm microcontrollers - mcu kinetis E 32-bit mcu, arm cortex-M0+ cor	arm microcontrollers - mcu kinetis E 32-bit mcu, arm cortex-M0+ cor	arm microcontrollers - mcu kinetis E 32-bit mcu, arm cortex-M0+ cor	IC mcu 32bit 64kb flash 80qfp	IC mcu 32bit 64kb flash 44qfp	IC mcu 32bit 64kb flash 64qfp
Program Memory Size	64KB (64K x 8)	128 kB	128 kB	128 kB	128 kB	64KB (64K x 8)	64KB (64K x 8)	-
Program Memory Type	FLASH	Flash	Flash	Flash	Flash	FLASH	FLASH	-
Package / Case	64-LQFP	LQFP-44	LQFP-64	QFP-64	LQFP-80	80-LQFP	44-LQFP	-

Recommended Resources

HT-680/HT-6187/HT-600/HT-6207/HT-640/HT-6247 electric line-a

High-precision nanoamp level current generator circuit diagram

Light controlled oscillator circuit

AC 220V power indicator light circuit schematic diagram

Capacitive divider clamped single-ended flyback switching regulated power supply

Thermocouple temperature frequency conversion circuit
