74HC/HCT564
Octal D-type flip-flop; positive-edge
trigger; 3-state; inverting
Product specification
File under Integrated Circuits, IC06
December 1990
Philips Semiconductors
Product specification
Octal D-type flip-flop; positive-edge
trigger; 3-state; inverting
FEATURES
•
3-state inverting outputs for bus oriented applications
•
8-bit positive-edge triggered register
•
Common 3-state output enable input
•
Independent register and 3-state buffer operation
•
Output capability: bus driver
•
I
CC
category: MSI
GENERAL DESCRIPTION
The 74HC/HCT564 are high-speed Si-gate CMOS devices
and are pin compatible with low power Schottky TTL
(LSTTL). They are specified in compliance with JEDEC
standard no. 7A.
74HC/HCT564
The 74HC/HCT564 are octal D-type flip-flops featuring
separate D-type inputs for each flip-flop and inverting
3-state outputs for bus oriented applications. A clock (CP)
and an output enable (OE) input are common to all
flip-flops.
The 8 flip-flops will store the state of their individual
D-inputs that meet the set-up and hold times requirements
on the LOW-to-HIGH CP transition.
When OE is LOW, the contents of the 8 flip-flops are
available at the outputs.
When OE is HIGH, the outputs go to the high impedance
OFF-state. Operation of the OE input does not affect the
state of the flip-flops.
The “564” is functionally identical to the “574” but has
inverting outputs. The “564” is functionally identical to the
“534”, but has a different pinning.
QUICK REFERENCE DATA
GND = 0 V; T
amb
= 25
°C;
t
r
= t
f
= 6 ns
TYPICAL
SYMBOL
t
PHL/
t
PLH
f
max
C
I
C
PD
Notes
1. C
PD
is used to determine the dynamic power dissipation (P
D
in
µW):
P
D
= C
PD
×
V
CC2
×
f
i
+∑ (C
L
×
V
CC2
×
f
o
) where:
f
i
= input frequency in MHz
f
o
= output frequency in MHz
∑
(C
L
×
V
CC2
×
f
o
) = sum of outputs
C
L
= output load capacitance in pF
V
CC
= supply voltage in V
2. For HC the condition is V
I
= GND to V
CC
; for HCT the condition is V
I
= GND to V
CC
−
1.5 V
ORDERING INFORMATION
See
“74HC/HCT/HCU/HCMOS Logic Package Information”.
PARAMETER
propagation delay CP to Q
n
maximum clock frequency
input capacitance
power dissipation capacitance per flip-flop
notes 1 and 2
CONDITIONS
HC
C
L
= 15 pF; V
CC
= 5 V
15
127
3.5
27
HCT
16
62
3.5
27
ns
MHz
pF
pF
UNIT
December 1990
2
Philips Semiconductors
Product specification
Octal D-type flip-flop; positive-edge trigger;
3-state; inverting
PIN DESCRIPTION
PIN NO.
1
2, 3, 4, 5, 6, 7, 8, 9
10
11
19, 18, 17, 16, 15, 14, 13, 12
20
SYMBOL
OE
D
0
to D
7
GND
CP
Q
0
to Q
7
V
CC
NAME AND FUNCTION
74HC/HCT564
3-state output enable input (active LOW)
data inputs
ground (0 V)
clock input (LOW-to-HIGH, edge-triggered)
3-state flip-flop outputs
positive supply voltage
Fig.1 Pin configuration.
Fig.2 Logic symbol.
Fig.3 IEC logic symbol.
December 1990
3
Philips Semiconductors
Product specification
Octal D-type flip-flop; positive-edge trigger;
3-state; inverting
FUNCTION TABLE
OPERATING
MODES
load and read
register
load register and
disable outputs
Notes
INPUTS
OE
L
L
H
H
CP
↑
↑
↑
↑
D
n
l
h
l
h
74HC/HCT564
INTERNAL
FLIP-FLOPS
L
H
L
H
OUTPUTS
Q
0
to Q
7
H
L
Z
Z
1. H = HIGH voltage level
h = HIGH voltage level one set-up time prior to the LOW-to-HIGH
CP transition
L = LOW voltage level
l = LOW voltage level one set-up time prior to the LOW-to-HIGH
CP transition
Z = high impedance OFF-state
↑
= LOW-to-HIGH clock transition
Fig.4 Functional diagram.
Fig.5 Logic diagram.
December 1990
4
Philips Semiconductors
Product specification
Octal D-type flip-flop; positive-edge trigger;
3-state; inverting
DC CHARACTERISTICS FOR 74HC
For the DC characteristics see
“74HC/HCT/HCU/HCMOS Logic Family Specifications”.
Output capability: bus driver
I
CC
category: MSI
AC CHARACTERISTICS FOR 74HC
GND = 0 V; t
r
= t
f
= 6 ns; C
L
= 50 pF
T
amb
(°C)
74HC
SYMBOL PARAMETER
+25
min.
t
PHL
/ t
PLH
propagation delay
CP to Q
n
3-state output enable
time
OE to Q
n
3-state output disable
time
OE to Q
n
output transition time
typ.
50
18
14
44
16
13
50
18
14
14
5
4
80
16
14
60
12
10
5
5
5
6.0
30
35
14
5
4
6
2
2
0
0
0
38
115
137
max.
165
33
28
140
28
24
135
27
23
60
12
10
100
20
17
75
15
13
5
5
5
4.8
24
28
−40
to +85
min.
max.
205
41
35
175
35
30
170
34
29
75
15
13
120
24
20
90
18
15
5
5
5
4.0
20
24
−40
to +125
min.
max.
250
50
43
210
42
36
205
41
35
90
18
15
ns
74HC/HCT564
TEST CONDITIONS
UNIT
V
CC
WAVEFORMS
(V)
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
Fig.6
t
PZH
/ t
PZL
ns
Fig.8
t
PHZ
/ t
PLZ
ns
Fig.8
t
THL
/ t
TLH
ns
Fig.6
t
W
clock pulse width
HIGH or LOW
set-up time
D
n
to CP
hold time
D
n
to CP
maximum clock pulse
frequency
ns
Fig.6
t
su
ns
Fig.7
t
h
ns
Fig.7
f
max
MHz
Fig.6
December 1990
5
