Mas-Con
®
Series CE/CT
Connectors .100"
.100" (2.54 mm) End and
Through Connectors
Available in 2-28 Circuits
with Optional Cover
Dimensions
.57
(14.5)
.100
(2.54)
Snap-on Covers EC
Snap-on Covers TC
Strain Relief Combination Cover SCC
.17
(4.3)
.30
(7.6)
Dimensions - Dual Dims
No. of Circuits
2
a
Dim. in
in. / (mm)
b
3
4
5
6
7
8
9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
.200
(5.08)
.300
(7.62)
.400
(10.16)
.500
(12.70)
.600
(15.24)
.700
(17.78)
.800
(20.32)
.900
(22.86)
1.000
(25.40)
1.100
(27.94)
1.200
(30.48)
1.300
(33.02)
1.400
(35.56)
1.500
(38.10)
1.600
(40.64)
1.700
(43.18)
1.800
(45.72)
1.900
(48.25)
2.000
(50.80)
2.100
(53.34)
2.200
(55.88)
2.300
(58.42)
2.400
(60.96)
2.500
(63.50)
2.600
(66.04)
2.700
(68.58)
2.800
(71.12)
.100
(2.54)
.200
(5.08)
.300
(7.62)
.400
(10.16)
.500
(12.70)
.600
(15.24)
.700
(17.78)
.800
(20.32)
.900
(22.86)
1.000
(25.40)
1.100
(27.94)
1.200
(30.48)
1.300
(33.02)
1.400
(35.56)
1.500
(38.10)
1.600
(40.64)
1.700
(43.18)
1.800
(45.72)
1.900
(48.25)
2.000
(50.80)
2.100
(53.34)
2.200
(55.88)
2.300
(58.42)
2.400
(60.96)
2.500
(63.50)
2.600
(66.04)
2.700
(68.58)
s s
= Number of Circuits
No. of Circuits 2-28
*(Contact Factory For Circuit Availability)
Version
Wire Size
AWG 28
AWG 26
AWG 24
AWG 22
End Connector
CE100F28-
s s
CE100F26-
s s
CE100F24-
s s
CE100F22-
s s
Through Connector
CT100F28-
s s
CT100F26-
s s
CT100F24-
s s
CT100F22-
s s
AWG Identification
Green
Blue
Black
Red
Color
Dimension
c inches (mm)
.27 (6.9)
.30 (7.6)
Snap-on Cover for End connectors
Snap-on Cover for Through connectors
Strain Relief Combination Cover
EC 100F-
s s
TC 100F-
s s
SCC100F-
s s
7
