MAX7384CVVT Overview

Analog Circuit, 1 Func, BICMOS, PDSO5, MO-187CAA, MICRO, SOP-8

MAX7384CVVT Parametric

Parameter Name	Attribute value
Maker	Maxim
Parts packaging code	TSSOP
package instruction	MO-187CAA, MICRO, SOP-8
Contacts	8
Reach Compliance Code	compliant
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	S-PDSO-G5
length	3 mm
Number of functions	1
Number of terminals	5
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	SQUARE
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Certification status	Not Qualified
Maximum seat height	1.1 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2.7 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BICMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	3 mm
Base Number Matches	1

Preview

Download Datasheet

View All

19-3493; Rev 1; 2/05

Silicon Oscillator with Low-Power Frequency

Switching and Reset Output

General Description

The MAX7384 dual-speed silicon oscillator replaces

ceramic resonators, crystals, and crystal-oscillator

modules as the primary and secondary clock source for

microcontrollers in 3V, 3.3V, and 5V applications. The

MAX7384 features a factory-programmed high-speed

oscillator, a 32.768kHz oscillator, a clock-selector input,

and a µP power-on-reset (POR) supervisor. The clock

output can be switched at any time between the high-

speed clock and the 32.768kHz clock for low-power

operation. Switchover is synchronized internally to pro-

vide glitch-free clock switching.

Unlike typical crystal and ceramic-resonator oscillator

circuits, the MAX7384 is resistant to vibration and EMI.

The high-output-drive current and absence of high-

impedance nodes makes the oscillator less susceptible

to dirty or humid operating conditions. With a wide oper-

ating temperature range as standard, the MAX7384 is a

good choice for demanding home appliance, industrial,

and automotive environments.

The MAX7384 is available with factory-programmed fre-

quencies ranging from 10MHz to 32MHz. See Table 1

for standard frequencies and contact the factory for

custom frequencies. Refer to the MAX7378 data sheet

for frequencies less than 10MHz.

The MAX7384 is available in an 8-pin µMAX

package.

The MAX7384 standard operating temperature range is

-40°C to +125°C. See the

Applications Information

sec-

tion for extended operating temperature range.

Features

♦

2.7V to 5.5V Operation

♦

High-Speed Oscillator from 10MHz to 32MHz

Low-Speed 32kHz Oscillator

Glitch-Free Clock-Speed Switching

♦

Integrated POR

♦

±10mA Clock-Output Drive Capability

♦

2.5% Initial Accuracy

♦

±50ppm/°C Frequency Drift

♦

50% Duty Cycle

♦

5ns Output Rise and Fall Time

♦

Low Jitter: 80ps

P-P

at 16MHz

♦

4mA Operating Current at 16MHz

♦

13µA, 32kHz Operating Current

♦

-40°C to +125°C Temperature Range

MAX7384

Ordering Information

PART*

MAX7384A_ _ _

MAX7384B_ _ _

MAX7384C_ _ _

TEMP RANGE

PIN-

PACKAGE

RESET

OUTPUT

Active high

push-pull

Active low

push-pull

Open drain

-40°C to +125°C 8 µMAX

Applications

White Goods

Automotive

Consumer Products

Appliances and Controls

Handheld Products

Portable Equipment

Microcontroller Systems

*Standard

version is shown in bold. The first letter after the part

number designates the reset output option. Insert the letter

corresponding to the desired reset threshold level from Table 1

in the next position. Insert the two-letter code from Table 2 in

the remaining two positions for the desired frequency range.

Table 1 and Table 2 are located at the end of the data sheet.

Typical Application Circuit

2.7V TO 5.5V

0.1µF

CLOCK

OSC1

OSC2

MAX7384

E.C.

RST/RST

SPEED

GND

RST

I/O PORT

µC

µMAX is a registered trademark of Maxim Integrated Products, Inc.

Pin Configuration appears at end of data sheet.

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
