25 to 30 Watt
2x2 Inch Metal Case H
2:1 Input Range
o Wide Input Range
o Pi Input Filter
o Single, Dual & Triple Output
o Remote On/Off Control
o Continuous Short Circuit Protection
o Efficiency up to 85%
MODEL NUMBER
25HRS12W3.3LC
25HRS12W5LC
30HRS12W12LC
30HRS12W15LC
25HRD12W5LC
30HRD12W12LC
30HRD12W15LC
30HRT12W5/12LC
30HRT12W5/15LC
25HRS24W3.3LC
25HRS24W5LC
30HRS24W12LC
30HRS24W15LC
25HRD24W5LC
30HRD24W12LC
30HRD24W15LC
30HRT24W5/12LC
30HRT24W5/15LC
25HRS48W3.3LC
25HRS48W5LC
30HRS48W12LC
30HRS48W15LC
25HRD48W5LC
30HRD48W12LC
30HRD48W15LC
30HRT48W5/12LC
30HRT48W5/15LC
last up-date 02.06.2005
INPUT
VOLTAGE
OUTPUT
VOLTAGE
3.3 VDC
5 VDC
12 VDC
15 VDC
OUTPUT
CURRENT
5000 mA
5000 mA
INPUT CURRENT
% EFF
NO LOAD
FULL LOAD
1860 mA
2675 mA
30 mA
3050 mA
74
78
82
78
82
2500 mA
2000 mA
±2500 mA
±1250 mA
3050 mA
±1000 mA
+3500/±310 mA
2640 mA
79
75
79
82
79
85
+3500/±250 mA
5000 mA
5000 mA
2500 mA
1525 mA
2000 mA
±2500 mA
±1250 mA
1470 mA
±1000 mA
+3500/±310 mA
1320 mA
80
75
79
82
79
85
+3500/±250 mA
5000 mA
5000 mA
20 mA
2500 mA
765 mA
2000 mA
±2500 mA
±1250 mA
735 mA
±1000 mA
+3500/±310 mA
655 mA
80
+3500/±250 mA
25 mA
660 mA
460 mA
660 mA
30 mA
1336 mA
920 mA
1336 mA
35 mA
2675 mA
9-18 VDC
±5 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
18-36 VDC
±5 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
36-72 VDC
±5 VDC
±12 VDC
±15 VDC
5/±12 VDC
5/±15 VDC
25 to 30 Watt - 2x2 Inch - Package H - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
2/3
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
2:1
Pi Type
OUTPUT SPECIFICATIONS
Single & Dual +Output
Dual
-Output
Triple 5V Output
Triple 12V/15V Output
±2% max.
±3% max.
±2% max.
±5% max.
±1% max.
<500 µsec.
±10%
10 mV RMS max.
75 mV p-p max.
±0.02%/°C max.
Continuous
Single & Dual Output
Triple Output
Single & Dual Output
Triple Output
±0.5% max.
±1% max.
±1% max.
±5% max.
Voltage Accuracy
Voltage Balance, Dual Output at Full Load
Transient Response
Single, 25% Step Load Change
Dual, Full Load to Half Load ±1% Error Band
External Trim Adj. Range
Ripple and Noise at 20MHz BW
Temperature Coefficient
Short Circuit Protection
Line Regulation
1)
Load Regulation
2)
NOTE:
1. Line Regulation measured from High Line to Low Line.
2. Load Regulation measured from Full Load to 1/4 Load.
GENERAL SPECIFICATION
Efficiency
Case Grounding
Isolation Voltage
Isolation Resistance
Switching Frequency
Operating Temperature Range
Storage Temperature Range
Derating >+60°C
Cooling
EMI/RFI
Case Material
MTBF (MIL-HDBK-217F)
Dimensions
see table
Connected to Output Common
500 VDC min.
1000 Mohms
300 kHz
-25°C to + 60°C
-55°C to + 105°C
-2.5%/°C
Free-Air Convection
Six-Sided Continuous Shield
Black Coated Copper with Non-Conductive Base
min. 790.000 hrs
2x2x0.4 Inches (50.8x50.8x10.2 mm)
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
25 to 30 Watt - 2x2 Inch - Package H - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/3
MECHANICAL SPECIFICATIONS
CASE "H"
PIN
1
2
3
4
5
6
7
8
PIN CONNECTIONS
SINGLE
DUAL
TRIPLE
REMOTE ON/OFF CONTROL
NO PIN
-INPUT
+INPUT
TRIM
-OUTPUT
+OUTPUT
NO PIN
NO PIN
-INPUT
+INPUT
TRIM
-OUTPUT
COMMON
+OUTPUT
NO PIN
-INPUT
+INPUT
-AUX. OUT
COMMON
+5V OUT
+AUX. OUT
APPLICATION NOTES & DIAGRAMS
REMOTE ON/OFF CONTROL
Logic Compatibility
Ec-ON
Ec-OFF
Shutdown Idle Current
Control Common
CMOS or Open Collector TTL
>+5.5VDC or Open Circuit
<1.8VDC
10mA
Referenced to Input Minus
TRIPLE OUTPUT LOADING
1)
OUTPUT
(PIN NO.)
7
8&5
8&5
AMPERES
VOLTAGE
MIN.
2)
+5 VDC
±12 VDC
±15 VDC
0.5 A
0.1 A
0.1 A
NOM.
3.5 A
0.31 A
0.25 A
NOTE:
1) Maximum total power from all outputs is limited to 25 watts but no output
should be allowed to exceed its maximum current.
2) Minimum current on each output is required to maintain specified
regulation.
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
