.100
[2.54] 2 ROW ELEVATED SOCKET
Specifications
Current Rating:
Insulator Resistance:
Contact Resistance:
Dielectric Withstanding:
Operating Temperature:
Contact Material:
Insulator Material:
Finish:
3 Amps
5000 Megohms min
20m ohms max
AC 1000V
-40° ~± 105° C
Phosphor Bronze
Polyester, UL 94V-0, PBT
See Contact Plating
.0197 [.500] +.100 [2.54] X No of Positions
.100 [2.54] X (No of Contacts/2-1)
.100 [2.54]
.197 [5.00]
R
C
R
Recognized under the recognized component
Program of Underwriters Laboratories, Inc.
Products specifications are subject to be changed
without notice.
.008 [1.95]
.244 [6.20]
.335 [8.50]
A
.100 [2.54]
B
PIN .0236 X .0236
.100 [2.54]
.100 [2.54]
Recommended P.C.B Layout
Dimensions are in inches [mm]
PART NUMBERING
93 XX S
SERIES CODE
NO. OF CONTACTS
04
to
80
P 12
XX
XX
CONTACT PLATING
Lead Free & RoHS Compliant
.000050” Nickel underplate
CONTACT
03
= Gold Flash
80
= 10
μ
” Gold
85
= 15
μ
” Gold
90
= 30
μ
” Gold
STACKING HEIGHT
A
01
= .435 [11.05]
02
= .435 [11.05]
03
= .535 [13.59]
04
= .635 [16.13]
05
= .435 [11.05]
06
= .535 [13.59]
07
= .635 [16.13]
08
= .735 [18.67]
B
.098 [2.50]
.289 [7.35]
.191 [4.85]
.091 [2.30]
.480 [12.2]
.380 [9.65]
.280 [7.10]
.181 [4.60]
CONSULT FACTORY FOR CONNECTORS BUILT TO YOUR DESIGN
WWW.ECSCONN.COM
