32-Lane 24-Port PCIe® Gen2

System Interconnect Switch with

Non-Transparent Bridging

89HPES32NT24AG2

Product Brief

Device Overview

The 89HPES32NT24AG2 is a member of the IDT family of PCI

Express® switching solutions. The PES32NT24AG2 is a 32-lane, 24-

port system interconnect switch optimized for PCI Express Gen2 packet

switching in high-performance applications, supporting multiple simulta-

neous peer-to-peer traffic flows. Target applications include multi-host or

intelligent I/O based systems where inter-domain communication is

required, such as servers, storage, communications, and embedded

systems.

With Non-Transparent Bridging functionality and innovative Switch

Partitioning feature, the PES32NT24AG2 allows true multi-host or multi-

processor communications in a single device. Integrated DMA control-

lers enable high-performance system design by off-loading data transfer

operations across memories from the processors. Each lane is capable

of 5 GT/s link speed in both directions and is fully compliant with PCI

Express Base Specification 2.1.

Features

◆

High Performance Non-Blocking Switch Architecture

–

32-lane, 24-port PCIe switch with flexible port configuration

–

Integrated SerDes supports 5.0 GT/s Gen2 and 2.5 GT/s

Gen1 operation

–

Delivers up to 32 GBps (256 Gbps) of switching capacity

–

Supports 128 Bytes to 2 KB maximum payload size

–

Low latency cut-through architecture

–

Supports one virtual channel and eight traffic classes

◆

Port Configurability

–

Four x8 stacks

•

Two x8 stacks, each configurable as:

• One x8 port

• Two x4 ports

• Four x2 ports

• Eight x1 ports

• Several combinations of the above lane widths

•

Two x4 stacks configurable as:

• One x8 port

• Two x4 ports

• Four x2 ports

• Several combinations of the above lane widths

–

Automatic per port link width negotiation

(x8

→

x1)

–

Crosslink support

–

Automatic lane reversal

–

Per lane SerDes configuration

•

De-emphasis

•

Receive equalization

•

Drive strength

Innovative Switch Partitioning Feature

–

Supports up to 8 fully independent switch partitions

–

Logically independent switches in the same device

–

Configurable downstream port device numbering

–

Supports dynamic reconfiguration of switch partitions

•

Dynamic port reconfiguration — downstream, upstream,

non-transparent bridge

•

Dynamic migration of ports between partitions

•

Movable upstream port within and between switch partitions

◆

Non-Transparent Bridging (NTB) Support

–

Supports up to 8 NT endpoints per switch, each endpoint can

communicate with other switch partitions or external PCIe

domains or CPUs

–

6 BARs per NT Endpoint

•

Bar address translation

•

All BARs support 32/64-bit base and limit address translation

•

Two BARs (BAR2 and BAR4) support look-up table based

address translation

–

32 inbound and outbound doorbell registers

–

4 inbound and outbound message registers

–

Supports up to 64 masters

–

Unlimited number of outstanding transactions

◆

Multicast

–

Compliant with the PCI-SIG multicast

–

Supports 64 multicast groups

–

Supports multicast across non-transparent port

–

Multicast overlay mechanism support

–

ECRC regeneration support

◆

Integrated Direct Memory Access (DMA) Controllers

–

Supports up to 2 DMA upstream ports, each with 2 DMA chan-

nels

–

Supports 32-bit and 64-bit memory-to-memory transfers

•

Fly-by translation provides reduced latency and increased

performance over buffered approach

•

Supports arbitrary source and destination address alignment

•

Supports intra- as well as inter-partition data transfers using

the non-transparent endpoint

–

Supports DMA transfers to multicast groups

–

Linked list descriptor-based operation

–

Flexible addressing modes

•

Linear addressing

•

Constant addressing

◆

Quality of Service (QoS)

–

Port arbitration

◆

IDT and the IDT logo are registered trademarks of Integrated Device Technology, Inc.

1 of 7

2009 Integrated Device Technology, Inc.

September 15, 2009
