HCMOS, 7.5x5mm, 1.8V, SMD Oscillator
Model: F4500 SERIES
Page 1 of 2
RoHS & REACH Compliant
Rev. 9/17/2012
http://www.foxonline.com/need_a_sample.htm
FEATURES
•
1.8V Operation
•
•
•
•
HCMOS Output
Low Power Consumption
Standby Function
Tape and Reel
(2,000 pcs. STD)
• PART nUMbER SELECTIOn
Part Number
528-Frequency-xxxxx
529-Frequency-xxxxx
530-Frequency-xxxxx
531-Frequency-xxxxx
532-Frequency-xxxxx
533-Frequency-xxxxx
534-Frequency-xxxxx
Model Frequency
Number Stability
1
F4500
±100PPM
F4500R
±100PPM
F4505
±50PPM
F4505R
±50PPM
F4506
±25PPM
F4506R
±25PPM*
F4508
±20PPM*
Operating
Temperature (ºC)
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
Frequency
Range (MHz)
1.800 ~ 160.000
1.800 ~ 160.000
1.800 ~ 160.000
1.800 ~ 160.000
1.800 ~ 160.000
1.800 ~ 160.000
1.800 ~ 125.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 32.100 MHz
32.100+ ~ 70.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (20% ~ 80% V
dd
) (T
r
)
1.800 ~ 32.100 MHz
32.100+ ~ 70.000 MHz
Fall Time (80% ~ 20% V
dd
) (T
f
)
1.800 ~ 32.100 MHz
32.100+ ~ 70.000 MHz
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Standby Current
Start-up Time
(T
s
)
Output Disable Time
2
Output Enable Time
2
1
MAX
(unless otherwise noted)
1.800 ~ 160.000 MHz
-55ºC ~ +125ºC
1.8V ± 5%
7mA
15mA
40% ~ 60%
5nS
3.5nS
5nS
3.5nS
20% V
dd
80% V
dd
Min
2mA Min
2mA Min
15pF
10µA
10mS
300nS
10mS
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration. *Excludes Shock/Vibration
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
Drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may vary.
All specifications subject to change without notice.
All dimensions are in millimeters.
• EnAbLE / DISAbLE FUnCTIOn
INH (Pin 1)
OUTPUT (Pin 3)
OPEN
2
ACTIVE
'1' Level V
ih
≥
70% V
dd
ACTIVE
'0' Level V
il
≤
30% V
dd
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
www.foxonline.com
EMEA
Tel: +44 .1283.568153 |
Canada
+1.888.438.2369 |
Asia
Hong Kong Tel: +852.2854.4285 |
Japan
Tel: +81.3.3374.2079
© 2012 FOX ELECTRONICS | ISO9001:2008 Certified
HCMOS, 7.5x5mm, 1.8V, SMD Oscillator
Model: F4500 SERIES
Page 2 of 2
RoHS & REACH Compliant
Rev. 9/17/2012
http://www.foxonline.com/need_a_sample.htm
• TAPE SPECIFICATIOnS
(millimeters)
MODEL
F4500 Series
• REEL SPECIFICATIOnS
(millimeters)
G H
I
J
K
L M
2.0
∅13 ∅21 ∅80 ∅255
17.5 2.0
b
C D E
F
STD Reel QTY
MODEL
A
F4500 Series
2,000
∅1.5
4.0 8.0 7.5 16.0 2.15
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
www.foxonline.com
EMEA
Tel: +44 .1283.568153 |
Canada
+1.888.438.2369 |
Asia
Hong Kong Tel: +852.2854.4285 |
Japan
Tel: +81.3.3374.2079
© 2012 FOX ELECTRONICS | ISO9001:2008 Certified
