5962F9862401VXX Overview

AC SERIES, QUAD 2-INPUT OR GATE, CDFP14

5962F9862401VXX Parametric

Parameter Name	Attribute value
Parts packaging code	DFP
package instruction	DFP,
Contacts	14
Reach Compliance Code	unknown
series	AC
JESD-30 code	R-CDFP-F14
Logic integrated circuit type	OR GATE
Number of functions	4
Number of entries	2
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Package shape	RECTANGULAR
Package form	FLATPACK
propagation delay (tpd)	12 ns
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Maximum seat height	2.92 mm
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
total dose	300k Rad(Si) V
width	6.285 mm
Base Number Matches	1

Preview

Download Datasheet

View All

ACS32MS

Data Sheet

November 1998

File Number

4545

Radiation Hardened Quad 2-Input OR Gate

The Radiation Hardened ACS32MS is a Quad 2-Input OR

Gate. For each gate, a HIGH level on either A or B input

results in a HIGH level on the Y output. A LOW level on both

the A and B inputs results in a LOW level on the Y output. All

inputs are buffered and the outputs are designed for

balanced propagation delay and transition times.

The ACS32MS is fabricated on a CMOS Silicon on Sapphire

(SOS) process, which provides an immunity to Single Event

Latch-up and the capability of highly reliable performance in

any radiation environment. These devices offer signiﬁcant

power reduction and faster performance when compared to

ALSTTL types.

Speciﬁcations for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed below must be used when ordering.

Detailed Electrical Speciﬁcations for the ACS32MS are

contained in SMD 5962-98624. A “hot-link” is provided

on our homepage with instructions for downloading.

www.intersil.com/data/sm/index.asp

Features

• QML Qualiﬁed Per MIL-PRF-38535 Requirements

• 1.25 Micron Radiation Hardened SOS CMOS

• Radiation Environment

- Latch-Up Free Under any Conditions

- Total Dose. . . . . . . . . . . . . . . . . . . . . . 3 x 10

RAD (Si)

- SEU Immunity . . . . . . . . . . . . . <1 x 10

-10

Errors/Bit/Day

- SEU LET Threshold . . . . . . . . . . . . >100MeV/(mg/cm

)

• Input Logic Levels . . . . V

= (0.3)(V

), V

= (0.7)(V

)

• Output Current . . . . . . . . . . . . . . . . . . . . . . . .

±8mA

(Min)

• Quiescent Supply Current . . . . . . . . . . . . . . 100µA (Max)

• Propagation Delay . . . . . . . . . . . . . . . . . . . . . . 12ns (Max)

Applications

• High Speed Control Circuits

• Sensor Monitoring

• Low Power Designs

Ordering Information

ORDERING NUMBER

5962F9862401VCC

ACS32D/SAMPLE-03

5962F9862401VXC

ACS32K/SAMPLE-03

5962F9862401V9A

INTERNAL MKT. NUMBER

ACS32DMSR-03

ACS32D/SAMPLE-03

ACS32KMSR-03

ACS32K/SAMPLE-03

ACS32HMSR-03

TEMP. RANGE (

-55 to 125

PACKAGE

14 Ld SBDIP

14 Ld Flatpack

Die

DESIGNATOR

CDIP2-T14

CDFP4-F14

N/A

Pinouts

ACS32MS

(SBDIP)

TOP VIEW

A1 1

B1 2

Y1 3

A2 4

B2 5

Y2 6

GND 7

14 V

13 B4

12 A4

11 Y4

10 B3

9 A3

8 Y3

ACS32MS

(FLATPACK)

TOP VIEW

GND

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

5962F9862401VXX Related Products

	5962F9862401VXX	5962F9862401VCX	5962F9862401V9X
Description	AC SERIES, QUAD 2-INPUT OR GATE, CDFP14	AC SERIES, QUAD 2-INPUT OR GATE, CDIP14	QUAD 2-INPUT OR GATE, UUC14
package instruction	DFP,	,	DIE,
Reach Compliance Code	unknown	unknown	unknown
JESD-30 code	R-CDFP-F14	R-CDIP-T14	X-XUUC-N14
Logic integrated circuit type	OR GATE	OR GATE	OR GATE
Number of functions	4	4	4
Number of entries	2	2	2
Number of terminals	14	14	14
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR	UNSPECIFIED
Package form	FLATPACK	IN-LINE	UNCASED CHIP
propagation delay (tpd)	12 ns	12 ns	12 ns
Certification status	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	NO	YES
technology	CMOS	CMOS	CMOS
Terminal form	FLAT	THROUGH-HOLE	NO LEAD
Terminal location	DUAL	DUAL	UPPER
total dose	300k Rad(Si) V	300k Rad(Si) V	300k Rad(Si) V
series	AC	AC	-
Maximum operating temperature	125 °C	125 °C	-
Minimum operating temperature	-55 °C	-55 °C	-
encapsulated code	DFP	-	DIE
Temperature level	MILITARY	MILITARY	-
Base Number Matches	1	1	-
