Type 381LR 105 °C Highest Ripple, Snap-In Aluminum
Ultra-High Ripple Capabilities
Compared to standard 105 °C snap-ins like the Type 381L/LX
Type 381LR can handle an extra 25% ripple current or more.
This remarkable capability stems from advances in electrolyte
that give extremely low ESR values.In high ripple current
applications like motor drives you can save by using fewer
capacitors.
Highlights
- The right choice for motor drive bus capacitors
- The right choice for UPS bus capacitors
- Compare to Type 381L
- Up to 2 times the ripple current
Specifications
Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
Ripple Current Multipliers
–40 °C to + 105 °C ≤ 315 Vdc
–25 °C to + 105 °C ≥ 350 Vdc
200 Vdc to 450 Vdc
56 µF to 2,200 µF
± 20%
≤3 √CV µA, 4 mA max, 5 minutes
Ambient Temperature
45 ºC
2.35
Frequency
10
50 Hz 60 Hz 120 Hz 500 kHz 1 kHz kHz &
Up
0.75
Low Temperature Characteristics
Endurance Life Test
0.80
1.00
1.20
1.25
1.40
60 ºC
2.20
70 ºC
2.00
85 ºC
1.70
105 ºC
1.00
Impedance ratio: Z
–20⁰C
∕ Z
+25⁰C
≤ 3 (200–450Vdc)
3000 h at full load at 105 °C
∆ Capacitance ±20%
ESR 200% of limit
DCL 100% of limit
1000 h at 105 °C
∆ Capacitance ±20%
ESR 200% of limit
DCL 100% of limit
10 to 55 Hz, 0.06” and 10 g max, 2 h each plane
RoHS Compliant
Shelf Life Test
Vibration
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
Ultra-High Ripple Capabilities
Part Numbering System
381LR
271
M
Type 381LR 105 °C Highest Ripple, Snap-In Aluminum
200
H01
Case
Type
381LR
Cap
271
= 270 µF
222
= 2200 µF
Tolerance
M =
±20%
Voltage
160
= 160 Vdc
450
= 450 Vdc
Code
2
Insulating
Sleeve
2
= PVC
+D
Blank =
no end disk if <250 V
D =
end disk, any voltage
Outline Drawing
+0.2
0.8 -0.1
6.3 1
2.0max.
4.0
Top of
Capacitor
Body
1.5 0.2
6.3 mm pin length
+0.2
0.8 -0.1
2.0max.
L ± 2 max.
3.5
4.0
1.5 0.2
Dimensions shown are in mm
Top of
Capacitor
Body
4.0 mm pin length
option (add “A” to end
of part#)
Note that for 200 volts and under the insulating end disc is optional - If one is needed add a (+D) to the end of the part numbering system.
Insulated Case Dimensions
Case
Code
H01
H02
H03
H04
H45
H05
J01
J02
J03
J04
J45
J05
DIAMETER
D
mm
22
22
22
22
22
22
25
25
25
25
25
25
inches
0.87
0.87
0.87
0.87
0.87
0.87
0.98
0.98
0.98
0.98
0.98
0.98
25
30
35
40
45
50
25
30
35
40
45
50
LENGTH
L
mm
inches
0.98
1.18
1.38
1.57
1.77
1.97
0.98
1.18
1.38
1.57
1.77
1.97
Typical
Weight
(grams)
16
19
22
24
28
31
20
24
27
31
35
38
Case
Code
K01
K02
K03
K04
K45
K05
A01
A02
A03
A04
A45
A05
A55
DIAMETER
D
mm
30
30
30
30
30
30
35
35
35
35
35
35
35
inches
1.18
1.18
1.18
1.18
1.18
1.18
1.38
1.38
1.38
1.38
1.38
1.38
1.38
25
30
35
40
45
50
25
30
35
40
45
50
55
LENGTH
L
mm
inches
0.98
1.18
1.38
1.57
1.77
1.97
0.98
1.18
1.38
1.57
1.77
1.97
2.17
Typical
Weight
(grams)
30
35
40
44
49
53
42
48
54
60
67
74
80
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
Type 381LR 105 °C Highest Ripple, Snap-In Aluminum
Ultra-High Ripple Capabilities
Ratings
ESR Max
@ 25º C
Cap.
(µF)
Catalog
Part Number
(Ω)
0.553
0.452
0.383
0.383
0.317
0.317
0.266
0.266
0.266
0.219
0.219
0.219
0.182
0.182
0.182
0.182
0.149
0.149
0.149
0.124
0.124
0.099
0.099
0.083
0.066
0.678
0.553
0.553
0.452
0.452
0.383
0.383
0.383
0.317
0.317
0.317
0.266
0.266
0.266
0.219
(Ω)
0.249
0.203
0.172
0.172
0.143
0.143
0.120
0.120
0.120
0.099
0.099
0.099
0.082
0.082
0.082
0.082
0.067
0.067
0.067
0.062
0.062
0.050
0.050
0.041
0.040
0.305
0.249
0.249
0.203
0.203
0.172
0.172
0.172
0.143
0.143
0.143
0.120
0.120
0.120
0.099
Ripple Amps
@ 105 ºC
(A)
1.42
1.56
1.71
1.71
1.85
1.85
2.14
2.14
2.14
2.42
2.42
2.42
2.63
2.63
2.63
2.63
2.84
2.84
2.84
3.13
3.13
3.56
3.56
3.84
4.12
1.28
1.42
1.42
1.64
1.64
1.72
1.72
1.72
1.85
1.85
1.85
2.14
2.14
2.14
2.42
(A)
2.03
2.23
2.44
2.44
2.64
2.64
3.05
3.05
3.05
3.45
3.45
3.45
3.76
3.76
3.76
3.76
4.06
4.06
4.06
4.47
4.47
5.06
5.06
5.48
5.89
1.83
2.03
2.03
2.34
2.34
2.45
2.45
2.45
2.64
2.64
2.64
3.05
3.05
3.05
3.45
Nominal
Size
D x L
(mm)
22 X 25
22 X 30
22 X 30
25 X 25
22 X 35
25 X 30
22 X 40
25 X 30
30 X 25
22 X 45
25 X 35
30 X 30
22 X 50
25 X 40
30 X 30
35 X 25
25 X 45
30 X 35
35 X 30
30 X 40
35 X 35
30 X 50
35 X 40
35 X 45
35 X 50
22 X 30
22 X 30
25 X 25
22 X 35
25 X 30
22 X 40
25 X 30
30 X 25
22 X 45
25 X 35
30 X 30
25 X 40
30 X 30
35 X 25
25 X 45
68
82
82
82
Cap.
(µF)
Catalog
Part Number
ESR Max
@ 25º C
(Ω)
0.219
0.219
0.182
0.182
0.149
0.149
0.124
0.099
1.617
1.326
1.960
1.105
1.105
1.105
1.105
1.105
0.737
0.737
0.737
0.603
0.603
0.603
0.603
0.491
0.491
0.491
0.402
0.402
0.34
0.34
0.282
0.237
1.95
1.617
1.617
1.326
1.326
1.105
1.105
(Ω)
0.099
0.099
0.082
0.082
0.067
0.067
0.062
0.050
0.728
0.597
0.960
0.497
0.497
0.387
0.387
0.387
0.322
0.322
0.322
0.271
0.271
0.271
0.271
0.221
0.221
0.221
0.181
0.181
0.153
0.153
0.127
0.107
0.878
0.728
0.728
0.597
0.597
0.497
0.497
Ripple Amps
@ 105 ºC
(A)
2.42
2.42
2.63
2.63
2.84
2.84
3.13
3.56
0.8
0.91
0.91
1.02
1.02
1.07
1.07
1.07
1.12
1.12
1.12
1.42
1.42
1.42
1.42
1.56
1.56
1.56
1.71
1.71
1.85
1.85
2.01
2.35
0.76
0.8
0.8
0.91
0.91
1.02
1.02
(A)
3.45
3.45
3.76
3.76
4.06
4.06
4.47
5.06
1.14
1.3
1.3
1.46
1.46
1.53
1.53
1.53
1.6
1.6
1.6
2.03
2.03
2.03
2.03
2.23
2.23
2.23
2.44
2.44
2.64
2.64
2.87
3.36
1.08
1.14
1.14
1.3
1.3
1.46
1.46
Nominal
Size
D x L
(mm)
30 X 35
35 X 30
30 X 40
35 X 35
30 X 50
35 X 40
35 X 45
35 X 50
22 X 25
22 X 30
25 X 25
22 X 35
25 X 30
22 X 40
25 X 30
30 X 25
22 X 45
25 X 35
30 X 30
22 X 50
25 X 40
30 X 30
35 X 25
25 X 45
30 X 35
35 X 30
30 X 40
35 X 30
30 X 45
35 X 35
35 X 40
35 X 45
22 X 25
22 X 30
25 X 25
22 X 30
25 X 25
22 X 35
25 X 30
120 Hz 20 kHz 120 Hz 20 kHz
200 Vdc (250 Vdc Surge)
120 Hz 20 kHz 120 Hz 20 kHz
250 Vdc (300 Vdc Surge)
270 381LR271M200H012
330 381LR331M200H022
390 381LR391M200H022
390 381LR391M200J012
470 381LR471M200H032
470 381LR471M200J022
560 381LR561M200H042
560 381LR561M200J022
560 381LR561M200K012
680 381LR681M200H452
680 381LR681M200J032
680 381LR681M200K022
820 381LR821M200H052
820 381LR821M200J042
820 381LR821M200K022
820 381LR821M200A012
1000 381LR102M200J452
1000 381LR102M200K032
1000 381LR102M200A022
1200 381LR122M200K042
1200 381LR122M200A032
1500 381LR152M200K052
1500 381LR152M200A042
1800 381LR182M200A452
2200 381LR222M200A052
220 381LR221M250H022
270 381LR271M250H022
270 381LR271M250J012
330 381LR331M250H032
330 381LR331M250J022
390 381LR391M250H042
390 381LR391M250J022
390 381LR391M250K012
470 381LR471M250H452
470 381LR471M250J032
470 381LR471M250K022
560 381LR561M250J042
560 381LR561M250K022
560 381LR561M250A012
680 381LR681M250J452
680 381LR681M250K032
680 381LR681M250A022
820 381LR821M250K042
820 381LR821M250A032
1000 381LR102M250K052
1000 381LR102M250A042
1200 381LR122M250A452
1500 381LR152M250A052
381LR820M400H012
400 Vdc (450 Vdc Surge)
100 381LR101M400H022
100 381LR101M400J012
120 381LR121M400H032
120 381LR121M400J022
150 381LR151M400H042
150 381LR151M400J022
150 381LR151M400K012
180 381LR181M400H452
180 381LR181M400J032
180 381LR181M400K022
220 381LR221M400H052
220 381LR221M400J042
220 381LR221M400K022
220 381LR221M400A012
270 381LR271M400J452
270 381LR271M400K032
270 381LR271M400A022
330 381LR331M400K042
330 381LR331M400A022
390 381LR391M400K452
390 381LR391M400A032
470 381LR471M400A042
560 381LR561M400A452
381LR680M420H012
381LR820M420H022
381LR820M420J012
250 Vdc (300 Vdc Surge)
420 Vdc (470 Vdc Surge)
100 38L1R101M420H022
100 381LR101M420J012
120 381LR121M420H032
120 381LR121M420J022
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
Type 381LR 105 °C Highest Ripple, Snap-In Aluminum
Ultra-High Ripple Capabilities
ESR Max
@ 25º C
Cap.
(µF)
Catalog
Part Number
(Ω)
0.884
0.737
0.737
0.737
0.737
0.603
0.603
0.603
0.491
0.491
0.491
0.402
0.402
0.34
0.34
0.282
2.368
1.95
1.95
1.617
1.617
(Ω)
0.398
0.332
0.332
0.332
0.332
0.271
0.271
0.271
0.221
0.221
0.221
0.181
0.181
0.153
0.153
0.127
1.066
0.878
0.878
0.728
0.728
Ripple Amps
@ 105 ºC
(A)
1.07
1.12
1.12
1.12
1.12
1.42
1.42
1.42
1.68
1.68
1.68
1.78
1.78
1.91
1.91
2.23
0.67
0.76
0.76
0.8
0.8
(A)
1.53
1.6
1.6
1.6
1.6
2.03
2.03
2.03
2.4
2.4
2.4
2.54
2.54
2.73
2.73
3.18
0.95
1.08
1.08
1.14
1.14
Nominal
Size
D x L
(mm)
30 X 25
22 X 45
25 X 40
30 X 30
35 X 25
25 X 45
30 X 35
35 X 30
25 X 50
30 X 40
35 X 30
30 X 45
35 X 35
30 X 50
35 X 40
35 X 45
22 X 25
22 X 30
25 X 25
22 X 30
25 X 25
Cap.
(µF)
Catalog
Part Number
ESR Max
@ 25º C
(Ω)
1.326
1.326
1.105
1.105
1.105
0.884
0.884
0.884
0.884
0.737
0.737
0.737
0.737
0.603
0.603
0.603
0.491
0.491
0.402
0.402
0.34
0.282
(Ω)
0.597
0.597
0.497
0.497
0.497
0.396
0.396
0.396
0.396
0.332
0.332
0.332
0.332
0.271
0.271
0.271
0.221
0.221
0.181
0.181
0.153
0.127
Ripple Amps
@ 105 ºC
(A)
0.91
0.91
1.02
1.02
1.02
1.07
1.07
1.07
1.07
1.12
1.12
1.12
1.12
1.42
1.42
1.42
1.72
1.72
1.85
1.85
1.97
2.47
(A)
1.3
1.3
1.46
1.46
1.46
1.53
1.53
1.53
1.53
1.6
1.6
1.6
1.6
2.03
2.03
2.03
2.45
2.45
2.64
2.64
2.82
3.53
Nominal
Size
D x L
(mm)
22 X 35
25 X 30
22 X 40
25 X 35
30 X 25
22 X 45
25 X 40
30 X 30
35 X 25
22 X 50
25 X 40
30 X 30
35 X 25
25 X 45
30 X 35
35 X 30
30 X 40
35 X 35
30 X 50
35 X 40
35 X 40
35 X 50
120 Hz 20 kHz 120 Hz 20 kHz
420 Vdc (470 Vdc Surge)
120 Hz 20 kHz 120 Hz 20 kHz
450 Vdc (500 Vdc Surge)
150 381LR151M420K012
180 381LR181M420H452
180 381LR181M420J042
180 381LR181M420K022
180 381LR181M420A012
220 381LR221M420J452
220 381LR221M420K032
220 381LR221M420A022
270 381LR271M420J052
270 381LR271M420K042
270 381LR271M420A022
330 381LR331M420K452
330 381LR331M420A032
390 381LR391M420K052
390 381LR391M420A042
470 381LR471M420A452
56
68
68
82
82
381LR560M450H012
381LR680M450H022
381LR680M450J012
381LR820M450H022
381LR820M450J012
100 381LR101M450H032
100 381LR101M450J022
120 381LR121M450H042
120 381LR121M450J032
120 381LR121M450K012
150 381LR151M450H452
150 381LR151M450J042
150 381LR151M450K022
150 381LR151M450A012
180 381LR181M450H052
180 381LR181M450J042
180 381LR181M450K022
180 381LR181M450A012
220 381LR221M450J452
220 381LR221M450K032
220 381LR221M450A022
270 381LR271M450K042
270 381LR271M450A032
330 381LR331M450K052
330 381LR331M450A042
390 381LR391M450A042
470 381LR471M450A052
450 Vdc (500 Vdc Surge)
Typical Performance Curves
6
Δ Capacitance and DF (%)
Life Test 105 ⁰C, Full Load, 220 µF, 400 Vdc
Capacitance, DF, Leakage Current
35
30
7
6
5
4
3
2
1
0
-1
0
Life Test 105 ⁰C, Full Load, 330 µF, 400 Vdc
Capacitance, DF, Leakage Current
DF
80
70
60
Δ Capacitance and DF (%)
5
4
3
2
1
0
-1
0
500
1000
1500
1000
DF
25
DCL
DCL (µA)
20
15
10
40
DCL
30
20
C
5
0
2000
C
500
1000
1500
10
0
2000
Hours @ Rated Max Temp, Voltage, Ripple
Type 381LR Operating Life in Kilohours vs Ripple Current
45 ºC
55 ºC
Hours @ Rated Max Temp, Voltage, Ripple
Expected Operating Life, kh
65 ºC
100
75
ºC
85 ºC
95 ºC
10
105 ºC
1
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
1.3
1.4
1.5
Rated Ripple-Current Multiple
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
DCL (µA)
50
Notice and Disclaimer:
All product drawings, descriptions, specifications, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confirming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifically and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specific customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specified by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
京公网安备 11010802033920号
EEWORLD
