MXH205048AH-4.000MHZ-T datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> MXH205048AH-4.000MHZ-T

MXH205048AH-4.000MHZ-T: DescriptionHCMOS Output Clock Oscillator, 4MHz Nom, SMD, 4 PIN; CategoryPassive components oscillator; File Size126KB，2 Pages; ManufacturerAbracon; Websitehttp://www.abracon.com/index.htm; Environmental Compliance

Download Datasheet Parametric View All

MXH205048AH-4.000MHZ-T Overview

HCMOS Output Clock Oscillator, 4MHz Nom, SMD, 4 PIN

MXH205048AH-4.000MHZ-T Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	4030121860
package instruction	SMD, 4 PIN
Reach Compliance Code	compliant
YTEOL	6.44
Other features	TRI-STATE; ENABLE/DISABLE FUNCTION
maximum descent time	4 ns
Frequency Adjustment - Mechanical	NO
frequency stability	50%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	4
Nominal operating frequency	4 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	HCMOS
Output load	15 pF
Package body material	CERAMIC
Encapsulate equivalent code	LCC4,.08X.1,67/53
physical size	2.6mm x 2.1mm x 0.9mm
longest rise time	4 ns
Maximum slew rate	7 mA
Maximum supply voltage	2.75 V
Minimum supply voltage	2.25 V
Nominal supply voltage	2.5 V
surface mount	YES
maximum symmetry	45/55 %
Terminal surface	GOLD OVER NICKEL

Preview

Download Datasheet

View All

MXH Series 2.0 x 2.5 Ceramic SMD Oscillator



Low Profile SMD Package



Hermetically Sealed



Wide Frequency Range



Custom Options Available

Frequency Range

Temperature Stability*

Operating Temperature Range

Storage Temperature Range

Aging (+25°C ±3°C)

Supply Voltage ±10% (Vdd)

Supply Current

1.544MHZ to 9.999MHZ

10.000MHZ to 34.999MHZ

35.000MHZ to 49.999MHZ

50.000MHZ to 66.000MHZ

1.544MHZ to 66.000MHZ

(See Part Number Guide for Options)

-40°C to +85°C

±5ppm for first year

+2.50 VDC

+3.30 VDC

+5.00 VDC

7mA max

8mA max

10mA max

8mA max

10mA max

20mA max

25mA max

50mA max

30mA max

35mA max

60mA max

HCMOS

10% Vdd max

90% Vdd min

4nSec

15pF

(See Part Number Guide for Options)

10mSec max

1pSec

Voh = 70% of Vdd min to Enable Output

max or grounded to Disable Output (High Impedance)

<7 Micro Amps

+1.80 VDC

6mA max

7mA max

15mA max

25mA max

Waveform

Logic “0”

Logic “1”

Rise/Fall Time (10% to 90% of Supply Voltage)

Load

Symmetry (50% of waveform)

Start-up Time

Absolute Clock Period Jitter

Tri-State Operation

Standby Current (only with “S” Option)

* Inclusive of Temperature., Load and Voltage

Vol = 30%

Environmental & Mechanical Detail

Shock

Solderability

Solvent Resistance

Vibration

Gross Leak Test

Fine Leak Test

MSL

MIL-STD-883, Method 2002 Cond B

MIL-STD-883, Method 2003

MIL-STD-202, Method 215

MIL-STD-883, Method 2007, Cond A

MIL-STD-883, Method 1014, Cond C

MIL-STD-883, Method 1014, Cond A2

Level 1 per IPC/JEDEC J-STD 20

Marking Detail

First Line =

XX.XX

(5 characters Max)

Device Frequency

= (four digits including decimal

point)

XX.XX

Second Line = SYWW

(5 characters Max)

Internal Code

S =

(may be one or two letters)

YWW = Date Code (Year/Week)

L = RoHS Compliant

Pin 1 Indicator

MMD Monitor/Quartztek

30400 Esperanza, Rancho Santa Margarita, CA, 92688

Phone: (949) 709-5075, Fax: (949) 709-3536,

www.mmdcomp.com

Sales@mmdcomp.com

Revision:

Subject to change without notice

120925K

Pg 1 of 2
