Power Inductors - Shielded
ctparts.com
CTDS3316 Series
From 1.0 µH to 1000 µH
ENGINEERING KIT #19
Not shown at actual size.
Part
Number
CTDS3316P_-102
CTDS3316P_-152
CTDS3316P_-222
CTDS3316P_-332
CTDS3316P_-472
CTDS3316P_-682
CTDS3316P_-103
CTDS3316P_-153
CTDS3316P_-223
CTDS3316P_-333
CTDS3316P_-473
CTDS3316P_-683
CTDS3316P_-104
CTDS3316P_-154
CTDS3316P_-224
CTDS3316P_-105
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTDS3316PF
Please specify “F” for RoHS Compliant
*40°C rise at Irms
**Inductance drop 10% typ. at Isat
Inductance
(µH)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
1000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω
)
0.021
0.022
0.032
0.039
0.054
0.075
0.101
0.150
0.207
0.334
0.472
0.660
1.110
1.550
2.000
8.300
*Irms
(A)
5.0
4.5
3.8
3.3
2.7
2.2
2.0
1.5
1.3
1.1
0.8
0.7
0.6
0.5
0.37
0.17
**Isat
(A)
5.6
5.2
5.0
3.9
3.2
2.8
2.4
2.0
1.6
1.4
1.0
0.9
0.8
0.6
0.5
0.32
SRF
Typ.
(MHz)
110
90
60
55
30
30
28
20
15
12
10
10
7
6
5
2
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
12.95
0.51
B
Max.
9.4
0.37
C
Max.
5.08
0.2
D
2.54
0.1
E
2.54
0.1
F
7.62
0.3
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Ideal for high performance DC/DC converter
applications, computers, LCD displays and telecommunication
equipment. Especially those requiring shielding
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on a HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Color dots(nH) OR stamped with Inductance code(µH).
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Parts will be marked with
Significant Digit Dots OR Inductance Code
A
1st significant digit
B
Ind. Code
XXX
3rd significant digit
2nd significant digit
PAD LAYOUT
C
D
E
F
