CAT9534YI-G: Description8 I/O, PIA-GENERAL PURPOSE, PDSO16, 4.40 MM, ROHS COMPLIANT, MO-153, TSSOP-16; CategoryThe embedded processor and controller Microcontrollers and processors; File Size985KB，17 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CAT9534YI-G Overview

8 I/O, PIA-GENERAL PURPOSE, PDSO16, 4.40 MM, ROHS COMPLIANT, MO-153, TSSOP-16

CAT9534YI-G Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	TSSOP
package instruction	TSSOP,
Contacts	16
Reach Compliance Code	unknown
JESD-30 code	R-PDSO-G16
JESD-609 code	e4
length	5 mm
Number of I/O lines	8
Number of ports	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Certification status	COMMERCIAL
Maximum seat height	1.1 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	2.3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	4.4 mm
uPs/uCs/peripheral integrated circuit type	PARALLEL IO PORT, GENERAL PURPOSE
Base Number Matches	1
