TD-125-G-C: DescriptionBoard Connector, 50 Contact(s), 2 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT; CategoryThe connector The connector; File Size373KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

TD-125-G-C Overview

Board Connector, 50 Contact(s), 2 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT

TD-125-G-C Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1613431478
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
YTEOL	9.1
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (20) OVER NICKEL (50)
Contact completed and terminated	GOLD OVER NICKEL
Contact point gender	MALE
Contact material	BRASS
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	50

Preview

Download Datasheet

View All

F-215

TD –108–G–AA

TS –119–G–A–1

HTS–115–T–C–2

(2,54 mm) .100"

TS, TD, HTS SERIES

PRECISION MACHINED TERMINAL STRIPS

SPECIFICATIONS

For complete speciﬁcations see

www.samtec.com?TS,

www.samtec.com?TD or

www.samtec.com?HTS

Insulator Material:

Black G.F. Polyester (TS, TD)

Black Liquid Crystal Polymer

(HTS)

Terminal Material:

Brass, except Style G is

Phosphor Bronze

Plating:

Au over 50µ" (1,27 µm) Ni or

Sn over 100µ" (2,54 µm) Cu

or 50µ" (1,27 µm) Ni

Operating Temp Range:

-55°C to +125°C with Gold

-55°C to +105°C with Tin

RoHS Compliant:

Yes

Lead-Free Solderable:

Wave only

Mates with:

SS, SD, HSS, SL,

SDL, ESS, ESD

Note:

Some lengths,

styles and options are

non-standard, non-returnable.

TYPE

STRIP

NO. PINS

PER ROW

PLATING

OPTION

LEAD

STYLE

= Single

Row Terminal

Strip

(2,54)

.100

(2,54) .100 x No. of Positions

= 20µ" (0,51 µm) Gold

Except –J & –L are

10µ" (0,25 µm) Gold

–G

(2,54)

.100 TYP

–T

= Tin

HTS

= Single Row

High Temp

Terminal Strip

(2,54)

.100

thru

=TS Series

(2,54) .100 x No. of Positions

(5,08)

.200

(2,54)

.100

(2,54)

.100 TYP

RECOGNITIONS

For complete scope

of recognitions see

www.samtec.com/quality

thru

= HTS & TD Series

= Double Row

Terminal Strip

(2,54)

.100

–AA

(0,46)

.018

DIA

(1,78)

.070

DIA

(0,46)

.018

DIA

(4,22)

.166

–A, –A–1, –A–2

(0,64)

.025

DIA

(1,78)

.070

DIA

(4,22)

.166

–C, –C–1, –C–2

(1,83)

.072

DIA

(3,99)

.157

(2,54)

.100

(0,89)

.035

LEAD

STYLE

-A

-A-1

-A-2

(DIA) (±.015)

(0,46) (3,96)

.018

.156

(0,64)

.025

(5,33)

(0,89) .210

.035

LEAD

STYLE

-C

-C-1

-C-2

(DIA) (±.015)

(0,46) (3,96)

.018

.156

(0,64)

.025

(5,33)

(0,89) .210

.035

(1,32)

.052

(3,96)

.156

±.015

(1,32)

.052

Component No. = T-1R5-

-A Component No. =T-1R0-

-A-X Component No. =T-1R7

-C Component No. =T-1R2-

-C-X Component No. =T-1R9-

–G–1

(0,51)

.020 DIA

(1,78)

.070 DIA

(0,51)

.020

(1,32)

.052 DIA

(0,46)

.018 DIA

(4,47)

.176

–J

(1,83)

.072

DIA

(7,62)

.300

± .015

(3,18)

.125

± .010

(1,07)

.042

DIA

(1,07)

.042

–L–1, –L–2, –L–3

(1,83)

.072 DIA

LEAD

STYLE

-L-1

-L-2

(DIA)

(12,95)

.510

(9,14)

.360

(6,60)

.260

(±.015)

(17,86)

.703

(14,05)

.553

(11,51)

.453

(12,90)

(1,02) .508

.040 ± .015

(4,75)

.187

(3,81)

.150

(1,32)

.052 DIA

(0,51)

.020 DIA

(0,76)

.030

(1,32)

.052

DIA

(0,64)

.025

Component No. = S-1W1

-L-3

Component No. = T-1R5-

Component No. = S-1P1-

WWW.SAMTEC.COM

Due to technical progress, all designs, speciﬁcations and components are subject to change without notice.
