FPS1000 Series

1000W Front End Power Supplies

Features



1U high



Up to 3000W (3 units) in 19” rack



Hotswap capable (ORing diodes built in)



Low Cost



PoE Option



High efﬁciency



Full array of signals

Key Market Segments & Applications

Speciﬁcations

Model

Output Voltage Range

(1)

Output Current

Line Regulation

Load Regulation

Output Noise

Overvoltage Protection

Overcurrent Protection

Load Sharing

Remote Sense

I2C Monitoring

Signals (opto isolated)

Remote On/Off

Auxiliary Output

AC Input

Leakage Current

Inrush Current

Hold up time (100VAC input)

Efﬁciency (typ) 100/200VAC

Power Factor Correction

Immunity

EMC (conducted and radiated)

Operating Temperature

Storage Temperature

Withstand Voltage

Cooling

Humidity

Shock & Vibration

Safety Agency

Input / Output Connector

Front panel indicators

Size (LxWxH)

Weight

Warranty

V

A

%

mV

V

-

A

-

mA

A

-

°C

-

in

g

yrs

12V Nominal

10.5 - 13.2V

72A

24V Nominal

21.5 - 29V

40A

<0.4%

<0.8%

200mV

250mV

300mV

31 to 34V

41.5V to 45.5V

62 to 66V

105 - 125%, Constant Current type

Single wire current sharing, up to 8 units

Compenstates for 1V on each output lead

Optional (Specify /S)

DC OK, AC Fail, and Overtemperature warning, high on fail

On: 0 - 0.6V or short, Off: 2- 15V or open

11.2-12.5VDC 0.25A

85 - 265VAC, 47 - 63Hz

2

, 120-360VDC* (Derate 10% < 100VAC)

<1.1mA at 230VAC input

<40A

20ms typical (800W loading)

80 / 83%

83 / 86%

84 / 87%

85 / 88%

EN61000-3-2 class A (20-100% load), >0.98 at full load

EN61000-4-2, -3, -4, -5, -6, -11

EN55022, level B, FCC Class B

0 to +70°C, derate 2%/°C from 50 to 60°C, 2.5%/°C from 60 to 70°C

-30 to +85°C

Input to Output 3kVAC, Input to Ground 2kVAC, Output to Ground 500VAC for 1 min.

Two internal fans, airﬂow from front to back (variable speed)

Operating: 10 - 90% RH, Storage: 10 - 95% RH (non condensing)

Meets ETS 300 019

UL60950-1, EN60950-1 (Ed 2), CE Mark

Positronic PCIB24W9M400A1 (Mating #PCIB24W9F400A1)

AC OK, DC OK, DC Fail

Stand alone: 1.61 x 5 x 11.4”; Rack: 1.72 x 19 x 13.8”

2,000

Two Years

*Safety certiﬁed for AC input only

150mV

14.3 to 15.7V

32V Nominal

28.8 - 38.4V

31A

48V Nominal

43 - 58V

21A

(1) Via Trim pin on output connector

(2) 47-440Hz with reduced PFC (100-265VAC input)
