AZ1641
MINIATURE
POWER RELAY
FEATURES
•
•
•
•
•
•
PC Terminals
SPDT through 4PDT arrangement
High switching capacity
AC and DC coils
UL, CUR file E43203
TÜV R50359828
CONTACTS
Arrangement
SPDT (1 Form C)
DPDT (2 Form C)
3PDT (3 Form C)
4PDT (4 Form C)
See chart on page 2
See chart on page 2
5A@ 220Vac/28Vdc, 100K 70°C
(Standard Duty only)
Silver cadmium oxide
< 50 milliohms initially
(24V, 1A voltage drop method)
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Operate Time
Release Time
Minimum operations
2 x 10
7
operations
1 x 10
5
operations at rated load
25ms max. at nominal coil voltage
25ms at nominal coil voltage
(without suppression)
Ratings
UL, CUR
TUV
Material
Resistance
Dielectric Strength
1500Vrms between contact and coil
(at sea level for 1 min.)
1000Vrms contact to contact
1000Vrms between contact sets
Insulation
Resistance
Dropout
Ambient Temperature
Operating
Storage
Vibration
100 megohms min. at 500VDC,
20°C, 50% RH
DC: > 10% of nominal coil voltage
AC: > 30% of nominal coil voltage
-40°C (-40°F) to 70°C (158°F)
-55°C (-67°F) to 105°C (221°F)
0.062" DA at 10–55 Hz
10 g
Polycarbonate
PC
250°C (482°F)
5 seconds
37 grams
COIL
Power
At Pickup Voltage
(typical)
Max. Continuous
Dissipation
Temperature
DC: 576mW, 6 to 48VDC
704mW, 110VDC
AC: 0.768VA
DC: 1.2W (110V : 1.5W) at 20°C (68°F)
AC: 1.7VA at 20°C (68°F)
105°C (221°F)
Shock
Enclosure
Terminals
Max. Solder Temp.
Max. Solder Time
Weight
(approx.)
NOTES
1. All values at 20°C (68°F).
2. Relay may pull in with less than “Must Operate” value.
3. Specifications subject to change without notice.
10/13/2016
AZ1641
CONTACT RATINGS
Maximum
Ratings
SPDT Heavy duty, resistive load:
Max. Switched Power: 560 W, 5540 VA
Max. Switched Current: 20 A
Max. Switched Voltage: 28 VDC, 277 VAC
DPDT Heavy duty, resistive load:
Max. Switched Power: 560 W, 5540 VA
Max. Switched Current: 10 A
Max. Switched Voltage: 28 VDC, 277 VAC
DPDT, 3PDT Standard duty, resistive load:
Max. Switched Power: 280 W, 2500 VA
Max. Switched Current: 10 A
Max. Switched Voltage: 28 VDC, 220 VAC
4PDT, Standard duty, resistive load:
Max. Switched Power: 280 W, 2500 VA
Max. Switched Current: 5 A
Max. Switched Voltage: 28 VDC, 220 VAC
UL/CUR
Ratings
SPDT Heavy duty:
20 A, 277 VAC, General use
20 A, 28 VDC, General use
DPDT Heavy duty:
10 A, 277 VAC, General use
10 A, 28 VDC, General use
1
/
2
HP, (9.8A) 125 VAC, Motor load
DPDT, 3PDT, Standard duty:
10 A, 220 VAC, General use
10 A, 28 VDC, General use
4PDT, Standard duty:
5A, 220 VAC, General use
5A, 28 VDC, General use
MECHANICAL DATA
AZ1641-_C
AZ164-_C
.039
(1.0)
.098
(2.5)
.846
(21.5)
AZ1641-_CT
.059
(1.5)
.196
(5.0)
.846
(21.5)
1.378
(35.0)
.157
(4.0)
.020
(0.5)
.138
(3.5)
1.102
(28.0)
1.378
(35.0)
.197
(5.0)
.020
(0.5)
.138
(3.5)
1.102
(28.0)
WIRING DIAGRAM
1
5
9
13
2
6
10
3
7
11
4
8
12
14
1
4
7
13
2
5
8
3
6
9
14
1
5
9
13
4
8
12
14
7
1
3
5
2
4
6
8
7
Viewed Towards Terminal
1
3
5
2
4
6
8
1
5
9
2
6
10
3
7
11
4
8
12
1
4
7
2
5
8
3
6
9
1
5
9
4
8
12
1
3
5
2
4
6
1
3
5
2
4
6
13
14
13
14
13
14
7
8
7
8
-
4C
4C
3C
2C
2CT
1CT
+
-
3C
+
-
2C
+
-
2CT
+
-
1CT
+
WITH LED
PC BOARD LAYOUTS
.169
(4.3)
.520
(13.2)
.169
(4.3)
.520
(13.2)
Viewed Towards Terminal
.226
(5.7)
.169
(4.3)
.520
(13.2)
.163
(4.1)
.161
(4.1)
.173
(4.4)
.163
(4.1)
.161
(4.1)
.260
(6.6)
.163
(4.1)
.161
(4.1)
.394
(10.0)
.156
(4.0)
.181
(4.6)
.417
(10.6)
.661
(16.8)
.409
(10.4)
.661
(16.8)
.409
(10.4)
.661
(16.8)
.409
(10.4)
ø.098 TYP
(ø2.5 TYP)
.699
(17.75)
ø.051 TYP
(ø1.3 TYP)
ø.051 TYP
(ø1.3 TYP)
ø.051 TYP
(ø1.3 TYP)
.559
(14.2)
4C
3C
2C
1CT & 2CT
10/13/2016
AZ1641
RELAY ORDERING DATA
STANDARD RELAYS: DC Coil
COIL SPECIFICATIONS
Nominal Coil
VDC
6
12
24
48
110
Must Operate
VDC
4.8
9.6
19.2
38.4
88.0
Max. Continuous
VDC
6.6
13.2
26.4
52.8
121.0
Nominal Current
mA ± 10%
150.0
75.0
36.9
18.5
10.0
Coil Resistance
Ohms ± 10%
40
160
650
2600
11,000
ORDER NUMBER*
AZ1641–2C–6D
AZ1641–2C–12D
AZ1641–2C–24D
AZ1641–2C–48D
AZ1641–2C–110D
STANDARD RELAYS: AC Coil (50/60 Hz)
COIL SPECIFICATIONS
Nominal Coil
VAC
6
12
24
48
120
220
Must Operate
VAC
4.8
9.6
19.2
38.4
96.0
176.0
Max. Continuous
VAC
7.1
14.3
28.6
57.1
143.0
261.0
Nominal Current
mA ± 10%
200.0
100.0
50.0
25.0
10.0
5.5
Coil Resistance
Ohms ± 10%
11.5
46
184
735
4,550
14,400
ORDER NUMBER*
AZ1641–2C–6A
AZ1641–2C–12A
AZ1641–2C–24A
AZ1641–2C–48A
AZ1641–2C–120A
AZ1641–2C–220A
* For 3PDT or 4PDT substitute “-3C” or “-4C” for “-2C”. For LED add “1” to the end of p/n.
RELAY ORDERING DATA
HEAVY DUTY RELAYS: DC Coil
COIL SPECIFICATIONS
Nominal Coil
VDC
6
12
24
48
110
Must Operate
VDC
4.8
9.6
19.2
38.4
88.0
Max. Continuous
VDC
6.6
13.2
26.4
52.8
121.0
Nominal Current
mA ± 10%
150.0
75.0
36.9
18.5
10.0
Coil Resistance
Ohms ± 10%
40
160
650
2600
11,000
ORDER NUMBER*
AZ1641–1CT–6D
AZ1641–1CT–12D
AZ1641–1CT–24D
AZ1641–1CT–48D
AZ1641–1CT–110D
HEAVY DUTY RELAYS: AC Coil (50/60 Hz)
COIL SPECIFICATIONS
Nominal Coil
VAC
6
12
24
48
120
220
240
Must Operate
VAC
4.8
9.6
19.2
38.4
96.0
176.0
192.0
Max. Continuous
VAC
7.1
14.3
28.6
57.1
143.0
261.0
288.0
Nominal Current
mA ± 10%
200.0
100.0
50.0
25.0
10.0
5.5
5.0
Coil Resistance
Ohms ± 10%
11.5
46
184
735
4,550
14,400
22,000
ORDER NUMBER*
AZ1641–1CT–6A
AZ1641–1CT–12A
AZ1641–1CT–24A
AZ1641–1CT–48A
AZ1641–1CT–120A
AZ1641–1CT–220A
AZ1641–1CT–240A
* For DPDT substitute “-2CT” for “-1CT”. For LED add “1” to the end of p/n.
10/13/2016
This specification provides an overview of the most significant part features. Any individual applications and operating conditions are not taken into consideration. It is recommended to test the product
under application conditions. Responsibility for the application remains with the customer. Proper operation and service life cannot be guaranteed if the part is operated outside the specified limits.
