ML61
ML61 Series Positive Voltage Detector
Application
Memory Battery Back-up Circuits
Microprocessor Reset Circuitry
Power Failure Detection
Power-on Reset Circuit
System Battery Life and Charge Voltage
Monitor
Features
CMOS Low Power Consumption : Typical 1.0uAat
Vin=2.0V
Selectable Detect V
oltage : 1.1V to 7.0V in 0.1V increments
HighlyAccurate : Detect V
oltage 1.1V to 1.9V + 3%
Detect V
oltage 2.0V to 7.0V + 2%
Operating V
oltage : 0.8V to 10.0V
PackageAvailable : SOT23 (150mW), SOT89 (500mW)
& TO92 (300mW)
General Description
The ML61 is a group of high-precision and low-power voltage detectors.
The ML61 consists of a highly-accurate and low-power reference voltage source, a comparator,
a hysteresis circuit, and an output driver. Detect voltage is very accurate and stable with
N-channel open drain and CMOS, are available.
Block Diagram
(1) CMOS Output
(2) N-Channel Open Drain Output
Absolute Maximum Ratings
Parameter
Input Voltage
Output Current
Output Voltage
Continuous SOT-23
Total Power SOT-89
Dissipation TO-92
Operating Ambient
Temperature
Storage Temperature
Symbol
V
IN
I
OUT
V
OUT
P
d
Ratings
10
50
V
SS
-0.3 ~V
IN
+0.3
150
500
300
T
opr
T
stg
P1/13
-40 ~ +70
-40 ~ +70
o
o
Units
V
mA
V
mW
C
C
Rev. H, August 2009
ML61
Pin Configuration
SOT-23-3
SOT-89-3
TO-92
Package Pin Number
SOT-23-3 SOT-89-3
TO-92
1
1
1
3
2
2
2
3
3
Pin Name
VOUT
VIN
VSS
Function
Supply Voltage Output
Supply Voltage Input
Ground
Test Circuits
Supply Current Test Circuit
Detector Threshold Test Circuit
Nch Driver Output Current Test Circuit
Pch Driver Output Current Test Circuit
P5/13
Rev. H, August 2009
