High-reliability discrete products
and engineering services since 1977
FEATURES
1N5063-1N4097,
MZ806-MZ210
3 WATT ZENER DIODES
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
Available as non-RoHS (Sn/Pb plating), standard, and as RoHS by adding “-PBF” suffix.
MAXIMUM RATINGS
Rating
Operating Temperature
Storage Temperature
-65 to 175°C
-65 to 200°C
Value
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Electrical Specifications @ 25°C
Type
(note 1)
Nominal
Zener
Voltage
V
Z
@ I
ZT
±5%
Tolerance
1N5063
1N5064
1N5065
1N5066
1N5067
1N4883
1N5069
1N5070
1N5071
1N5072
1N5073
1N4884
1N5074
1N5075
1N5076
1N5077
1N5078
1N5079
1N5081
1N5083
1N5085
1N5087
1N5088
1N5091
1N5092
±10%
Tolerance
MZ806
MZ807
MZ808
MZ809
MZ810
MZ812
MZ813
MZ814
MZ815
MZ816
MZ818
MZ820
MZ822
MZ824
MZ827
MZ830
MZ833
MZ836
MZ840
MZ845
MZ850
MZ856
MZ860
MZ870
MZ875
Volts
6.8
7.5
8.2
9.1
10.0
12
13
14
15
16
18
20
22
24
27
30
33
36
40
45
50
56
60
70
75
Test
Current
I
ZT
mA
75
75
75
75
75
65
50
50
50
50
40
40
30
30
25
25
20
20
20
15
15
10
10
10
10
Maximum Reverse Leakage
Current
I
R
@ V
R
µA
500
300
200
100
40
10
10
10
10
5
5
5
5
5
1
1
1
1
1
1
1
1
1
1
1
± 5% V
R
Volts
5.2
5.7
6.2
6.9
7.6
9.1
9.9
10.6
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
30.4
34.2
38.0
42.6
45.7
53.3
56.0
±10% V
R
Volts
4.9
5.4
5.9
6.6
7.2
8.6
9.3
10.1
10.8
11.5
12.9
14.4
15.8
17.3
19.4
21.6
23.7
25.9
28.8
32.4
36.0
40.3
43.2
50.5
54.0
Maximum
Zener
Impedance
Z
Z
@ I
ZT
Ohms
2
2
3
3
4
5
6
6
6
7
8
9
10
10
12
15
21
21
27
37
50
70
70
90
100
Typ. Temp.
Coefficient
T
C
@ I
ZT
%/°C
.04
.04
.05
.05
.06
.07
.07
.07
.07
.07
.08
.08
.08
.08
.09
.090
.090
.090
.095
.095
.095
.095
.095
.095
.095
Maximum Ratings
Maximum
Continuous
Current
I
ZM
mA
440
400
360
330
300
250
230
210
200
185
170
150
135
125
110
100
90
85
75
65
60
55
50
45
40
Maximum
Surge
Current
I
S
Amps
10.0
8.00
7.00
6.00
5.00
4.00
4.00
4.00
3.00
3.00
2.00
2.00
2.00
1.50
1.50
1.50
1.20
1.00
1.00
0.80
0.80
0.70
0.60
0.60
0.50
Rev. 20150416
High-reliability discrete products
and engineering services since 1977
1N5063-1N4097,
MZ806-MZ210
3 WATT ZENER DIODES
Electrical Specifications @ 25°C
Maximum
Zener
Impedance
Z
Z
@ I
ZT
Ohms
115
150
175
Maximum Ratings
Typ. Temp.
Coefficient
T
C
@ I
ZT
%/°C
.095
.095
.100
Maximum
Continuous
Current
I
ZM
mA
35
30
30
Maximum
Surge
Current
I
S
Amps
0.40
0.40
0.4
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Type
(note 1)
Nominal
Zener
Voltage
V
Z
@ I
ZT
±5%
Tolerance
1N5093
1N4096
1N4097
±10%
Tolerance
MZ880
MZ890
MZ210
Volts
80
90
100
Test
Current
I
ZT
mA
10
8.0
5.0
Maximum Reverse Leakage
Current
I
R
@ V
R
µA
1
1
100
± 5% V
R
Volts
60.8
68.5
76.0
±10% V
R
Volts
57.7
64.8
72.0
MECHANICAL CHARACTERISTICS
Case:
Marking:
Polarity:
Digi A
Body painted, alpha-numeric
Cathode band
Rev. 20150416
