APA3010HT datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> APA3010HT

APA3010HT: DescriptionSingle Color LED, Bright Red, Red Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN; CategoryLED optoelectronic/LED photoelectric; File Size495KB，6 Pages; ManufacturerKingbright; Websitehttp://www.us.kingbright.com; Environmental Compliance

Download Datasheet Parametric Compare View All

APA3010HT Overview

Single Color LED, Bright Red, Red Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN

APA3010HT Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Kingbright
package instruction	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
color	BRIGHT RED
Configuration	SINGLE
Maximum forward current	0.025 A
Lens type	RED TRANSPARENT
Nominal luminous intensity	1.3 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	3
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	2 mm
method of packing	TAPE
peak wavelength	700 nm
shape	RECTANGULAR
size	2 mm
surface mount	YES
perspective	120 deg
Base Number Matches	1

Preview

Download Datasheet

View All

Kingbright

Features

3.0x1.0mm RIGHT ANGLE SMD CHIP LED LAMPS

APA3010

Package Dimensions

3.0mmx1.0mm SMT LED. 2.0mm THICKNESS.

LOW POWER CONSUMPTION.

WIDE VIEWING ANGLE.

IDEAL FOR BACKLIGHT AND INDICATOR.

VARIOUS COLORS AND LENS TYPES AVAILABLE.

Description

The Bright Red source color devices are made with Gallium

Phosphide Red Light Emitting Diode.

The Super Bright Green source color devices are made with

Gallium Phosphide Green Light Emitting Diode.

The High Efficiency Red source color devices are made with

Gallium Arsenide Phosphide on Gallium Phosphide Orange

Light Emitting Diode.

The Yellow source color devices are made with Gallium

Arsenide Phosphide on Gallium Phosphide Yellow Light

Emitting Diode.

The Super Bright Red source color devices are made with

Gallium Aluminum Arsenide Red Light Emitting Diodes.

The Super Bright Yellow source color devices are made with

DH InGaAlP on GaAs substrate Light Emitting Diode.

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0

.1(0.004") unless otherwise noted.

3. Lead spacing is measured where the lead emerge package.

4. Specifications are subjected to change without notice.

Selection Guide

Part No.

APA3010HD

APA3010HC

APA3010HT

APA3010ID

APA3010EC

APA3010IT

APA3010YD

APA3010YC

APA3010YT

APA3010SRD

APA3010SRC

APA3010SRT

APA3010SGD

APA3010SGC

APA3010SGT

APA30102SYD

APA3010SYC

APA3010SYT

Dice

BRIGHT RED (GaP)

HIGH EFFICIENCY RED (GaAsP/GaP)

YELLOW (GaAsP/GaP)

SUPER BRIGHT RED (GaAlAs)

SUPER BRIGHT GREEN (GaP)

SUPER BRIGHT YELLOW (InGaAlP)

Lens Type

RED DIFFUSED

WATER CLEAR

RED TRAS.

RED DIFFUSED

WATER CLEAR

RED TRANS.

YELLOW DIFFUSED

WATER CLEAR

YELLOW TRANS.

RED DIFFUSED

WATER CLEAR

RED TRANS.

GREEN DIFFUSESD

WATER CLEAR

GREEN TRNS.

YELLOW DIFFUSESD

WATER CLEAR

YELLOW TRNS.

Iv (mcd)

@ 20 mA

Min.

0.8

3.2

Typ.

1.25

12.5

Viewing

Angle

2θ1/2

120°

Note:

1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.

APA3010-1

APA3010HT Related Products

	APA3010HT	APA3010SYD	APA3010SGT	APA3010SYT	APA3010SRC	APA3010IT	APA3010SRD	APA3010SRT
Description	Single Color LED, Bright Red, Red Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	SINGLE COLOR LED, SUPER BRIGHT YELLOW, 2mm, 3.0 X 1.0 MM, 2.0 MM HEIGHT, SMD, 3 PIN	Single Color LED, Super Bright Green, Green Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	Single Color LED, Super Bright Yellow, Yellow Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	Single Color LED, Super Bright Red, Water Clear, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	Single Color LED, High Efficiency Red, Red Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	Single Color LED, Super Bright Red, Diffused Red, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	Single Color LED, Super Bright Red, Red Transparent, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN
package instruction	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3.0 X 1.0 MM, 2.0 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN	3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
color	BRIGHT RED	SUPER BRIGHT YELLOW	SUPER BRIGHT GREEN	SUPER BRIGHT YELLOW	SUPER BRIGHT RED	HIGH EFFICIENCY RED	SUPER BRIGHT RED	SUPER BRIGHT RED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Maximum forward current	0.025 A	0.03 A	0.025 A	0.03 A	0.03 A	0.03 A	0.03 A	0.03 A
Lens type	RED TRANSPARENT	DIFFUSED YELLOW	GREEN TRANSPARENT	YELLOW TRANSPARENT	WATER CLEAR	RED TRANSPARENT	DIFFUSED RED	RED TRANSPARENT
Nominal luminous intensity	1.3 mcd	60.0 mcd	12.5 mcd	60.0 mcd	70.0 mcd	12.5 mcd	70.0 mcd	70.0 mcd
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	1	1	1	1	1	1	1	1
Number of terminals	3	3	3	3	3	3	3	3
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Optoelectronic device types	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
total height	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm
method of packing	TAPE	TAPE	TAPE	TAPE	TAPE	TAPE	TAPE	TAPE
peak wavelength	700 nm	595 nm	565 nm	595 nm	660 nm	625 nm	660 nm	660 nm
shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
size	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
perspective	120 deg	120 deg	120 deg	120 deg	120 deg	120 deg	120 deg	120 deg
Is it Rohs certified?	conform to	-	conform to	conform to	conform to	conform to	conform to	conform to
Maker	Kingbright	Kingbright	Kingbright	Kingbright	-	-	-	Kingbright
Base Number Matches	1	1	1	1	1	1	1	-
