1812SMS-27NGLD datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 1812SMS-27NGLD

1812SMS-27NGLD: DescriptionGeneral Purpose Inductor, 0.027uH, 2%, 1 Element, Air-Core, SMD, 1925, ROHS COMPLIANT; CategoryPassive components inductor; File Size295KB，2 Pages; ManufacturerCOILCRAFT; Websitehttp://www.coilcraft.com/; Environmental Compliance

Download Datasheet Parametric View All

1812SMS-27NGLD Overview

General Purpose Inductor, 0.027uH, 2%, 1 Element, Air-Core, SMD, 1925, ROHS COMPLIANT

1812SMS-27NGLD Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	1925
Reach Compliance Code	compli
ECCN code	EAR99
uppercase and lowercase codes	1925
structure	Flat T
core material	AIR
DC Resistance	0.004 Ω
Nominal inductance(L)	0.027 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e2
Number of functions	1
Number of terminals	2
Maximum operating temperature	140 °C
Minimum operating temperature	-40 °C
Package height	4.2 mm
Package length	4.95 mm
Package form	SMT
Package width	6.35 mm
method of packing	TR, 13 Inch
Minimum quality factor (at nominal inductance)	100
self resonant frequency	0.0027 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Tin/Silver (Sn96.5Ag3.5)
Terminal location	DUAL ENDED
Terminal shape	FLAT
Test frequency	150 MHz
Tolerance	2%
Base Number Matches	1

Preview

Download Datasheet

View All

Document 184-1

Midi Spring Air Core Inductors

• Air core inductors feature high Q and current handling

• Acrylic top provides a flat surface for pick and place

• Solder coated leads ensure reliable soldering

Weight

0.10 – 0.16 g

Terminations

RoHS compliant tin-silver over copper. Other

terminations available at additional cost.

Ambient temperature

–40°C to +125°C with

Irms

current, +125°C

to +140°C with derated current

Storage temperature

Component: –40°C to +140°C.

Tape and reel packaging: –40°C to +80°C

Resistance to soldering heat

Max three 40 second reflows at

+260°C, parts cooled to room temperature between cycles

Temperature Coefficient of Inductance (TCL)

+5 to +70 ppm/°C

Moisture Sensitivity Level (MSL)

1 (unlimited floor life at <30°C /

85% relative humidity)

Failures in Time (FIT) / Mean Time Between Failures (MTBF)

One per billion hours / one billion hours, calculated per Telcordia SR-332

Packaging

500/7″ reel; 2000/13″ reel Plastic tape: 12 mm wide,

0.3 mm thick, 8 mm pocket spacing, 4.33 mm pocket depth

PCB washing

Tested with pure water or alcohol only. For other

solvents, see Doc787_PCB_Washing.pdf

Part

number

Inductance

(nH)

100

120

150

Percent

tolerance

5,2

typ

135

130

135

125

120

115

125

145

min

100

Test freq.

(MHz)

150

SRF min

(GHz)

3.2

2.7

2.5

2.1

1.5

1.3

1.2

1.1

0.75

DCR max

(mOhm)

4.2

4.0

4.8

4.4

5.6

6.2

8.2

9.4

12.3

17.3

33.0

Irms

(A)

3.0

3.5

3.0

2.5

1.7

1.5

1.2

1812SMS-22N_L_

1812SMS-27N_L_

1812SMS-33N_L_

1812SMS-39N_L_

1812SMS-47N_L_

1812SMS-56N_L_

1812SMS-68N_L_

1812SMS-82N_L_

1812SMS-R10_L_

1812SMS-R12_L_

1812SMS-R15_L_

1. When ordering, specify

tolerance, termination

and

packaging

codes:

1812SMS-R12GLC

Tolerance: G

= 2%

= 5%

Termination: L

= RoHS compliant tin-silver (96.5/3.5) over copper.

Special order:

= RoHS tin-silver-copper

(95.5/4/0.5) or

= non-RoHS tin-lead (63/37).

Packaging: C

= 7″ machine-ready reel. EIA-481 embossed plastic

tape, 500 parts per full reel.

= Less than full reel. In tape, but not machine-ready.

To have a leader and trailer added ($25 charge),

use code letter C instead.

= 13″ machine-ready reel. EIA-481 embossed plastic

tape. Factory order only, not stocked, 2000 parts per

full reel.

2. Inductance tested at 150 MHz on an Agilent/HP 4286A LCR meter or

equivalent with a Coilcraft SMD-A test fixture and correlation.

3. Tolerances in bold are stocked for immediate shipment.

4. Q tested at 150 MHz on an Agilent/HP 4291A Impedance Analyzer with

an Agilent/HP 16193 test fixture or equivalents.

5. SRF tested on the Agilent/HP 8753D Network Analyzer or equivalent

and a Coilcraft CCF1248 test fixture.

6. DCR tested on the Cambridge Technology Model 510 Micro-ohmmeter

or equivalent.

7. Current that causes a 15°C temperature rise from 25°C ambient.

8. Electrical specifications at 25°C.

Refer to Doc 362 “Soldering Surface Mount Components” before soldering.

For part marking data see www.coilcraft.com/colrcode.cfm.

+1-847-639-6400 sales@coilcraft.com

+44-1236-730595 sales@coilcraft-europe.com

Taiwan

+886-2-2264 3646 sales@coilcraft.com.tw

China

+86-21-6218 8074 sales@coilcraft.com.cn

Singapore

+ 65-6484 8412 sales@coilcraft.com.sg

Document 184-1

Revised 02/19/13

This product may not be used in medical or high

risk applications without prior Coilcraft approval.

Specification subject to change without notice.

Please check web site for latest information.
