8-1617537-3: DescriptionPOWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT; CategoryMechanical and electronic products relay; File Size108KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

8-1617537-3 Overview

POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT

8-1617537-3 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum coil current (DC)	0.031 A
Coil power	369 mW
Coil resistance	390 Ω
Maximum coil voltage (DC)	12 V
Coil/Input Power Type	DC
Maximum contact current (AC)	1 A
Maximum contact current (DC)	1 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1617537
Installation features	THROUGH HOLE-STRAIGHT MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Relay action	MOMENTARY
Relay function	DPDT
Relay type	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED
surface mount	NO
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

HM-12A Product Details

Military/Aerospace High Performance Relays

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

HM-12A

(8-1617537-3)

T E I nternal N umber: 8 - 1 6 1 7 5 3 7 - 3

Product Highlights:

HM TO-5 Relay Series

Input Voltage = 12 VDC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact C urrent Rating = 1 Amps.

Non Polarized, Monostable C oil Magnetic System

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

RELAY

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = Long Leads

Electrical Characteristics:

Input Voltage (VDC ) = 12

C ontact C urrent Rating (Amps.) = 1

C oil Polarity Protection Diode = Without

Transistor Driver = Without

C oil Resistance (?) = 390

MOSFET Driver = Without

C oil Power Measurement = Milliwatts

C oil Power, Nominal (mW) = 369

Actuating System = DC

Shock = 30G's, 6ms

Vibration = 10G's, 10 to 500Hz

Body Related Features:

Series

= HM TO-5 Relay

Contact Related Features:

Mounting Options = PC Board

Enclosure = Hermetically Sealed

Configuration Related Features:

C ontact Arrangement

= 2 Form C , DPDT, 2 C /O

C oil Magnetic System = Non Polarized, Monostable

C oil Suppression Diode = Without

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Conditions for Usage:

Temperature Range (?C ) = -55 – +85

Other:

Brand = C II

Additional Information:

Product Line Information

8-1617537-3 Related Products

	8-1617537-3	HM-12A
Description	POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT	POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT
Maker	TE Connectivity	TE Connectivity
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Maximum coil current (DC)	0.031 A	0.031 A
Coil power	369 mW	369 mW
Coil resistance	390 Ω	390 Ω
Maximum coil voltage (DC)	12 V	12 V
Coil/Input Power Type	DC	DC
Maximum contact current (AC)	1 A	1 A
Maximum contact current (DC)	1 A	1 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	1617537	HM
Installation features	THROUGH HOLE-STRAIGHT MOUNT	THROUGH HOLE-STRAIGHT MOUNT
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-55 °C	-55 °C
Relay action	MOMENTARY	MOMENTARY
Relay function	DPDT	DPDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED	HERMETICALLY SEALED
surface mount	NO	NO
Termination type	SOLDER	SOLDER
