352345-3 Product Details
Live Product Chat
Product Photo
2mm Hard Metric PCB Mount Connectors (Z-PACK 2mm HM)
Always EU R oHS com plia nt but not ELV C om plia nt
(
Sta te m e nt of
C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
352345-3
T E I nternal N umber: 3 5 2 3 4 5 - 3
Product Highlights:
l
C onnector
l
C onnector Type = Type B, 25 C olumn
l
Receptacle
l
Interface Type = 2mm HM
l
C ontact Type = AC TION PIN Post, Signal
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
Z-PAC K 2MM HM TYPE B PRE-SHIELDED REC EPTAC LE WITH RE...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version D)
l
3D Model
(IGES, Version D)
l
3D Model
(STEP, Version D)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type = Type B, 25 C olumn
l
Gender
= Receptacle
l
Number of Positions
= 125
l
PC B Mount Angle
= Right Angle
l
Mating Polarization
= With
l
Mating Polarization Type
= Multi-Purpose C enter
l
Shielded
= Yes
l
Shield Material = Phosphor bronze
Mechanical Attachment:
l
Board Mount
= Free Board
l
Module Length (mm [in])
= 50.00 [1.968]
l
C rosstalk Version
= Reduced
l
AMP Standard Option Number = 1
l
Shield Type = Ground Return Shielding
l
Shield Style = Upper
Termination Related Features:
l
Interface Type
= 2mm HM
l
Termination End Plating = Tin-Lead over Nickel
Body Related Features:
l
Number of Rows
= 5
l
Grounding C ontact
= Without
l
Rows Loaded = A, E, D, B, C
l
Shield Plating = Gold Flash over Nickel
Contact Related Features:
l
C ontact Type = AC TION PIN Post, Signal
l
Feedthrough Post Length (mm [in])
= 3.71 [0.146]
l
C ompactPC I
= Yes
l
C ontact Mating Area Plating Material
= Gold (2)
l
C ontact Style = Short Tail
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester GF
l
Housing C olor = Gray
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS/Not ELV C ompliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS not ELV
compliant
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
