Coaxial
Power Splitter/Combiner
2 Way-0° Resistive 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-40°C to 85°C
-55°C to 100°C
0.16W max.
0.08W max.
ZX10R-14+
DC to 10000 MHz
Features
• very wideband, DC to 10000 MHz
• very good phase unbalance, 1 deg. typ.
• excellent amplitude unbalance, 0.02 dB typ.
• rugged shielded case
CASE STYLE: FL905
Connectors Model
Price
Qty.
SMA
ZX10R-14-S+
$69.95 ea. (1-9)
Applications
• laboratory
• test set-ups
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Electrical Specifications T
AMB
=25°C
FREQ.
RANGE
(MHz)
L
f
L
-f
U
DC-10000
Typ.
6.0
ISOLATION
(dB)
M
Typ.
6.0
U
Typ.
6.0
INSERTION LOSS (dB)
ABOVE 6.0 dB
L
Typ. Max.
0.1 0.2
M
Typ. Max.
0.5 1.0
U
Typ. Max.
1.5 1.8
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
3
U
Max.
6
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.1
M
Max.
0.2
U
Max.
0.3
Outline Drawing
L = low range [DC-1000 MHz]
M = mid range [1000 MHz to f
U
/2]
U= upper range [f
U
/2 to f
U
]
This is a resistive power divider to enable frequency coverage from dc to the highest rated frequency. Since resistive power divider do not
provide a high degree of isolation (basically isolation equals the insertion loss between ports), an amplifier such as Mini-Circuits' ZFL
series is recommended when high isolation is required. Matched power rating 0.16W, internal load dissipation 0.08W.
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
0.03
0.10
1.00
10.00
100.00
1000.00
5000.00
6000.00
7000.00
7500.00
6.03
6.01
6.00
6.02
6.00
6.06
6.73
6.93
7.28
7.45
7.55
7.53
7.42
7.31
7.31
Amplitude
Unbalance
(dB)
0.01
0.00
0.01
0.00
0.00
0.01
0.04
0.01
0.06
0.08
0.09
0.09
0.08
0.08
0.09
Isolation
(dB)
Phase
Unbalance
(deg.)
0.09
0.01
0.00
0.14
0.06
0.44
1.20
1.34
1.78
2.08
2.39
2.70
2.91
3.06
3.18
VSWR
S
VSWR
1
VSWR
2
S-2
6.02
6.01
6.01
6.02
6.00
6.07
6.77
6.92
7.21
7.37
7.46
7.44
7.34
7.23
7.22
6.04
6.02
6.01
6.03
6.00
6.04
6.09
6.04
5.99
6.02
6.09
6.17
6.25
6.26
6.20
1.00
1.00
1.00
1.02
1.00
1.01
1.22
1.25
1.26
1.24
1.22
1.20
1.19
1.20
1.23
ZX10R-14+
ISOLATION
7.0
ISOLATION (dB)
6.5
6.0
5.5
5.0
1.00
1.00
1.00
1.02
1.00
1.01
1.17
1.21
1.19
1.19
1.20
1.21
1.21
1.17
1.12
1.00
1.00
1.00
1.02
1.01
1.00
1.16
1.20
1.21
1.21
1.22
1.24
1.24
1.22
1.17
Outline Dimensions (
inch
)
mm
A
.74
18.80
H
.37
9.40
B
.90
22.86
J
--
--
C
.54
13.72
K
.122
3.10
D
.50
12.70
L
.496
12.60
E
.04
1.02
M
.106
2.69
F
.16
4.06
G
.29
7.37
N
wt
.122 grams
3.10
20.0
INSERTION LOSS (dB)
8000.00
8500.00
9000.00
9500.00
10000.00
ZX10R-14+
INSERTION LOSS
8.0
7.0
6.0
S-1(dB)
S-2(dB)
5.0
0
2000
4000
6000
8000
10000
FREQUENCY (MHz)
ZX10R-14+
VSWR
1.40
#S-VSWR
1.30
VSWR
1.20
1.10
1.00
0
2000
4000
6000
8000
10000
FREQUENCY (MHz)
#1-VSWR
#2-VSWR
0
2000
4000
6000
8000
10000
FREQUENCY (MHz)
electrical schematic
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
EW
ALL N
minicircuits.com
REV. OR
M112749
ED-12611/2
ZX10R-14+
HY/TD/CP
080226
