CLS Series
Current Sensing Chip Resistor
•
•
•
•
•
•
Resistances from 0.01 to 1Ohms
Power Rating 0.06 to 1 Watt
Resistance Tolerances to ± 1%
TCR’s to ±150 ppm/K
Alumina Substrate for High Power Dissipation
Sizes: 0402 / 0603 / 0805 / 1206 / 2010 / 2512
SPECIFICATIONS
Type
Power Rating
(W)
at 70°C
Resistance
Range (W)
Tolerances
Temperature
Coefficient
(depending on
value)
Operating Tem-
peratur range
Dimensions
(LxW)
mm
[inches]
Packaging (pcs)
Tape and Reel
1.00 x 0.50
[0.04 x 0.02]
10,000
1.60 x 0.80
[0.06 x 0.03]
±200 to ±400 ppm
CLS0402
0.0625
0.05 to 1.0
CLS0603
0.1
0.02 to 1.0
1% / 2% / 5%
±200 to ±600 ppm
±100 ppm upon request
CLS0805
0.125
CLS1206
0.25
CLS2010
0.5
0.01 to 1.0
CLS2512
1.0
-55 to +155°C
2.00 x 1.25
[0.08 x 0.05]
5,000
3.10 x 1.55
[0.12 x 0.06]
5.00 x 2.50
[0.20 x 0.10]
4,000
6.30 x 3.10
[0.25 x 0.12]
Pow er Derating Curve
100
80
Power (%)
60
40
20
0
0
20
40
60
70
80
100 120 140 155
Am bient Tem perature (°C)
Ordering Information
Part Number - Resistance - Tolerance - TCR - Packaging
Example: CLS 2512 0.500Ohms 1%
(Note: if no TCR is specified: The highest value will be supplied)
Powertron GmbH
Potsdamer Strasse 18a D-14513 Teltow
+49 (0)3328 3530-0
A Riedon Company
www.powertron.de
+49 (0)3328 3530-15
Page 11
1.01
