DP06S/D Series
6W DC/DC CONVERTER, DIP-Package, Wide 2:1 Input Range
FEATURES
E
fficiency up to 86%
DIP Package with Industry Standard Pinout
Wide 2:1 Input Range
Operating Temperature Range –40°C to +85°C
Isolation Voltage 1500VDC
Short Circuit Protection
CSA60950-1 Safety Approval
3 Years Product Warranty
The DP06S/D series are miniature, DIP Package, isolated 6W DC/DC converters with 1,500VDC isolation. It offers short circuit
protection and allows a wide operating temperature range of –40°C to +85°C. These isolated DC/DC converters are the latest
offering from a world leader in power systems technology and manufacturing
―
Delta Electronics, Inc. With creative design
technology and optimization of component placement, these converters possess outstanding electrical and thermal performance, as
well as extremely high reliability under highly stressful operating conditions.
Model List
Model
Number
Input
Voltage
(Range)
VDC
DP06S1203A
DP06S1205A
DP06S1212A
DP06D1212A
DP06D1215A
DP06S2403A
DP06S2405A
DP06S2412A
DP06D2412A
DP06D2415A
Output
Voltage
VDC
3.3
5
12
±12
±15
3.3
5
12
±12
±15
Output
Current
Max.
mA
1200
1000
500
±250
±200
1200
1000
500
±250
±200
Min.
mA
60
50
25
±12.5
±10
60
50
25
±12.5
±10
Input Current
@Max. Load
mA(typ.)
429
514
595
595
595
209
251
291
291
291
@No Load
mA(typ.)
Reflected
Ripple
Current
mA(typ.)
Max. capacitive
Load
uF
6800
20
25
1000*
Efficiency
(typ.)
@Max. Load
%
77
81
84
84
84
79
83
86
86
86
* For each output
12
(9 ~ 18)
24
(18 ~ 36)
6800
5
15
1000*
Input Characteristics
Parameter
Input Surge Voltage (1 sec. max.)
Start-Up Voltage
Under Voltage Shutdown
Reverse Polarity Input Current
Short Circuit Input Power
Internal Power Dissipation
Conducted EMI (with suffix E only)
All Models
Model
12V Input Models
24V Input Models
12V Input Models
24V Input Models
12V Input Models
24V Input Models
Min.
-0.7
-0.7
4.5
8
---
---
---
---
---
Typ.
---
---
6
12
---
---
---
1000
---
Max.
25
50
8
16
8
16
1
3000
2500
A
mW
mW
VDC
Unit
Compliance to EN 55022,class A and FCC part 15,class A
DS_DP06S/D_07182012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Output Characteristics
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Transient Recovery Time
Transient Response Deviation
Temperature Coefficient
Over Load Protection
Short Circuit Protection
Conditions
Dual Output, Balanced Loads
Vin=Min. to Max.
Io=20% to 100%
Over Line, Load & Temp.
25% Load Step Change
Foldback
Min.
---
---
---
---
---
---
---
---
---
---
120
Typ.
±0.5
±0.5
±0.1
±0.3
50
---
---
150
±2
±0.01
150
Continuous
Max.
±1.0
±2.0
±0.3
±1.0
75
100
15
300
±6
±0.02
---
Unit
%
%
%
%
mV
P-P
mV
P-P
mV rms
uS
%
%/℃
%
General Characteristics
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF (calculated)
Safety Approvals
MIL-HDBK-217F@25℃, Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Min.
1500
1000
---
---
1,000,000
Typ.
---
---
380
300
---
Max.
---
---
500
---
---
Unit
VDC
MΩ
pF
KHz
Hours
UL/cUL 60950-1 recognition(CSA certificate), IEC/EN 60950-1(CB-scheme)
Recommended Input Fuse
12V Input Models
1500mA Slow-Blow Type
24V Input Models
700mA Slow-Blow Type
Environmental Characteristics
Parameter
Operating Temperature Range (with
Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature (1.5mm from case for
10Sec.)
Conditions
Ambient
Min.
-40
---
-50
---
Free-Air convection
---
260
℃
Max.
+85
+90
+125
95
Unit
℃
℃
℃
% rel. H
DS_DP06S/D_07182012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Power Derating Curve
Notes
1
2
3
4
5
6
7
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Transient recovery time is measured to within 1% error band for a step change in output load of 75% to 100%
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will not
damage these modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
To order the converter with input filter meeting EN55022, Class A , add suffix E (e.g. Dp06s1203E) to order code.
Specifications subject to change without notice.
Mechancial Drawing
Mechanical Dimensions
10.2
[0.40]
Output Power (%)
Pin Connections
Pin
Single Output
2
-Vin
3
9
11
14
16
22
23
-Vin
No Pin
NC
+Vout
-Vout
+Vin
+Vin
Dual Output
-Vin
-Vin
Common
-Vout
+Vout
Common
+Vin
+Vin
0.50 [0.02]
15.22 [0.60]
2
3
9
11
4.1
[0.16]
Bottom View
23 22
16
14
2.54
[0.10]
15.24 [0.60]
31.8 [1.25]
5.08 4.5
[0.20][0.18]
2.54
[0.10]
20.3 [0.80]
NC: No Connection
►All
dimensions in mm (inches)
►Tolerance:
X.X±0.25 (X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
►Pin
diameter
⇔
0.5 ±0.05 (0.02±0.002)
Physical Outline
ase Size
Case Material
Weight
:
:
:
31.8x20.3x10.2mm (1.25x0.80x0.40 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
16.9g
DS_DP06S/D_07182012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Part Numbering System
D
Form factor
D-DIP
P-SIP
S-SMD
P
Family series
A~Z
06
Watt
01:1W
02:2W
03:3W
04:4W
06:6W
S
Number of
Outputs
S - Single
D- Dual
12
Input Voltage
03:3.3V
05: 5V
12:12V
24: 24V
48:48V
05
Output Voltage
03:3.3V
05: 5V
12:12V
15: 15V
24: 24V
A
Option Code
A - Std. Functions
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under
any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
DS_DP06S/D_07182012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P4
