SERIES:
VIBLSD1-DIP
│
DESCRIPTION:
DC-DC CONVERTER
FEATURES
• 1 W isolated output
• industry standard 14 pin DIP package
• single regulated outputs
• 1,000 V isolation
• short circuit protection
• wide temperature (-40~85°C)
• efficiency up to 75%
RoHS
MODEL
VIBLSD0.75-S5-S5-DIP
VIBLSD1-S5-S5-DIP
VIBLSD1-S5-S9-DIP
VIBLSD1-S5-S12-DIP
VIBLSD1-S5-S15-DIP
VIBLSD1-S5-S24-DIP
VIBLSD0.75-S12-S5-DIP
VIBLSD1-S12-S5-DIP
VIBLSD1-S12-S9-DIP
VIBLSD1-S12-S12-DIP
VIBLSD1-S12-S15-DIP
VIBLSD1-S12-S24-DIP
VIBLSD0.75-S24-S5-DIP
VIBLSD1-S24-S5-DIP
VIBLSD1-S24-S9-DIP
VIBLSD1-S24-S12-DIP
VIBLSD1-S24-S15-DIP
VIBLSD1-S24-S24-DIP
Notes:
input
voltage
typ
(Vdc)
range
(Vdc)
output
voltage
(Vdc)
output
current
min
(mA)
max
(mA)
output
power
max
(W)
ripple
1
max
(mVp-p)
noise
1
max
(mVp-p)
efficiency
typ
(%)
5
5
5
5
5
5
12
12
12
12
12
12
24
24
24
24
24
24
4.75~5.25
4.75~5.25
4.75~5.25
4.75~5.25
4.75~5.25
22.8~25.2
11.4~12.6
11.4~12.6
11.4~12.6
11.4~12.6
11.4~12.6
22.8~25.2
22.8~25.2
22.8~25.2
22.8~25.2
22.8~25.2
22.8~25.2
22.8~25.2
5
5
9
12
15
24
5
5
9
12
15
24
5
5
9
12
15
24
15
20
12
9
7
5
15
20
12
9
7
5
20
15
12
9
7
5
150
200
111
83
67
42
150
200
111
83
67
42
200
150
111
83
67
42
0.75
1
1
1
1
1
0.75
1
1
1
1
1
0.75
1
1
1
1
1
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
68
67
70
71
73
68
68
67
72
70
74
68
68
68
68
73
75
68
1. ripple and noise are measured at 20 MHz BW
PART NUMBER KEY
VIBLSDX - SXX - SXX -DIP
Base Number
Output Power
Output Voltage
Input Voltage
cui.com
Packaging Style
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VIBLSD1-DIP
│
DESCRIPTION:
DC-DC CONVERTER
date
07/11/2013
│
page
2 of 5
INPUT
parameter
operating input voltage
conditions/description
5 V model
12 V model
24 V model
min
4.75
11.4
22.8
typ
5
12
24
max
5.25
12.6
25.2
units
Vdc
Vdc
Vdc
OUTPUT
parameter
line regulation
load regulation
voltage accuracy
switching frequency
temperature coefficient
conditions/description
for Vin change of ±5%
measured from 10% load to full load
100% load
100% load, input voltage range
100
±0.03
min
typ
max
±0.25
±1
±3
units
%
%
%
kHz
%/°C
PROTECTIONS
parameter
short circuit protection
conditions/description
5 and 24 V output models
all other models: continuous
min
typ
max
1
units
s
SAFETY AND COMPLIANCE
parameter
isolation voltage
isolation resistance
MTBF
RoHS compliant
yes
conditions/description
for 1 minute at 1 mA max.
at 500 Vdc
min
1,000
1,000
3,500,000
typ
max
units
Vdc
MΩ
hours
ENVIRONMENTAL
parameter
operating temperature
storage temperature
storage humidity
temperature rise
lead temperature
non-condensing
at full load
1.5 mm from case for 10 seconds
15
conditions/description
min
-40
-55
typ
max
85
125
95
25
300
units
°C
°C
%
°C
°C
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VIBLSD1-DIP
│
DESCRIPTION:
DC-DC CONVERTER
date
07/11/2013
│
page
4 of 5
APPLICATION NOTES
1.
Requirement on Output Load
In order to ensure the product operates efficiently and reliably, make sure the specified range of input voltage is not exceeded and the
minimum output load is not less than 10% load. If the actual load is less than the specified minimum load, the output ripple may
increase sharply while its efficiency and reliability will reduce greatly. If the actual output power is very small, please add an
appropriate resistor as extra loading.
Overload Protection
Under normal operating conditions, the output circuit of these products has no protection against over-current and short-circuits. The
simplest method is to connect a self-recovery fuse in series at the input end or add a circuit breaker to the circuit.
Filtering
In some circuits which are sensitive to noise and ripple, a
fi
ltering capacitor may be added to the DC/DC output end and input end to
reduce the noise and ripple. However, the capacitance of the output
fi
lter capacitor must be proper. If the capacitance is too big, a
startup problem might arise. For every channel of output, provided the safe and reliable operation is ensured, the greatest
capacitance of its
fi
lter capacitor sees the external capacitor table. To get an extremely low ripple, an “LC”
fi
ltering network may be
connected to the input and output ends of the DC/DC converter, which may produce a more significant
fi
ltering effect. It should also
be noted that the inductance and the frequency of the “LC”
fi
ltering network should be staggered with the DC/DC frequency to avoid
mutual interference (Figure 1).
L
L
2.
3.
Figure 1
Vin
+Vo
C
GND
DC DC
C
0V
4.
Output Voltage Regulation and Over-voltage Protection Circuit
The simplest device for output voltage regulation, over-voltage and over-current protection is a linear voltage regulator with overheat
protection that is connected to the input or output end in series (Figure 2).
Figure 2
Vin
GND
REG
+Vout
DC DC
0V
5.
External Capacitor Table
It is not recommended to connect any external capacitor in the application
fi
eld with less than 0.5 W output.
Vin
(Vdc)
Cin
(μF)
4.7
4.7
2.2
1
--
Vout
(Vdc)
5
9
12
15
24
Cout
(μF)
10
4.7
2.2
1
0.47
Table 1
5
12
15
24
--
Note:
All specifications measured at 25°C, humidity <75%, nominal input voltage, and full load unless otherwise noted.
