ATF22V10CQ-15PC

Description
FLASH PLD, 15 ns, PDSO24
CategoryProgrammable logic devices    Programmable logic
File Size253KB，18 Pages
ManufacturerAtmel (Microchip)
Download Datasheet Parametric Compare View All

ATF22V10CQ-15PC Online Shopping

Suppliers Part Number Price MOQ In stock
ATF22V10CQ-15PC - - View Buy Now

ATF22V10CQ-15PC Overview

FLASH PLD, 15 ns, PDSO24

ATF22V10CQ-15PC Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeDIP
package instructionDIP, DIP24,.3
Contacts24
Reach Compliance Codecompli
ECCN codeEAR99
Factory Lead Time1 week
ArchitecturePAL-TYPE
maximum clock frequency55.5 MHz
JESD-30 codeR-PDIP-T24
JESD-609 codee0
length31.877 mm
Humidity sensitivity level1
Dedicated input times10
Number of I/O lines10
Number of entries22
Output times10
Number of product terms132
Number of terminals24
Maximum operating temperature70 °C
Minimum operating temperature
organize10 DEDICATED INPUTS, 10 I/O
Output functionMACROCELL
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Encapsulate equivalent codeDIP24,.3
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)225
power supply5 V
Programmable logic typeFLASH PLD
propagation delay15 ns
Certification statusNot Qualified
Maximum seat height5.334 mm
Maximum supply voltage5.25 V
Minimum supply voltage4.75 V
Nominal supply voltage5 V
surface mountNO
technologyCMOS
Temperature levelCOMMERCIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperature30
width7.62 mm
Base Number Matches1

Preview

Download Datasheet
Features
•
Industry-standard Architecture
•
•
•
•
•
– Low-cost, Easy-to-use Software Tools
High-speed, Electrically Erasable Programmable Logic Devices
– 5 ns Maximum Pin-to-pin Delay
CMOS- and TTL-compatible Inputs and Outputs
– Latch Feature Holds Inputs to Previous Logic States
Pin-controlled Standby Power (10 µA Typical)
Advanced Flash Technology
– Reprogrammable
– 100% Tested
High-reliability CMOS Process
– 20-year Data Retention
– 100 Erase/Write Cycles
– 2,000V ESD Protection
– 200 mA Latch-up Immunity
Dual Inline and Surface Mount Packages in Standard Pinouts
PCI-compliant
True Input Transition Detection “Z” and “QZ” Version
•
•
•
High-
performance
EE PLD
ATF22V10C
ATF22V10CQ
See separate datasheet
for ATF22V10CZ and
ATF22V10CQZ options.
24
23
22
21
20
19
18
17
16
15
14
13
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
IN
Pin Configurations
All Pinouts Top View
Pin Name
CLK
IN
I/O
GND
VCC
PD
Function
Clock
Logic Inputs
Bi-directional Buffers
Ground
+5V Supply
Power-down
PLCC
IN
IN
CLK/IN
VCC*
VCC
I/O
I/O
TSSOP
CLK/IN
IN
IN
IN/PD
IN
IN
IN
IN
IN
IN
IN
GND
1
2
3
4
5
6
7
8
9
10
11
12
DIP/SOIC
CLK/IN
IN
IN
IN/PD
IN
IN
IN
IN
IN
IN
IN
GND
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
IN
4
3
2
1
28
27
26
Note:
For all PLCCs (except “-5”), pins 1, 8, 15 and 22 can be
left unconnected. However, if they are connected, supe-
rior performance will be achieved.
Rev. 0735P–PLD–01/02
IN
IN
GND
GND*
IN
I/O
I/O
12
13
14
15
16
17
18
IN/PD
IN
IN
GND*
IN
IN
IN
5
6
7
8
9
10
11
25
24
23
22
21
20
19
I/O
I/O
I/O
GND*
I/O
I/O
I/O
1
