M40 Connectors
Vertical Surface Mount
1mm (.039") PITCH
Locating pegs to ensure correct positioning onto the board.
Polarised to prevent mis-mating.
Staggered pin-out to help board layout.
FEMALE
1.00
A
B
0.70
4.20
0.40
B+1
E
B+1
3.30
C
Ø1.30
B
1.00
1.30
6.00
3.40
1.95
Recommended PC Board Pattern
Ø1.20
D
CALCULATION
A
B
C
B + 7.1
(Total No. Of Contacts – 3) / 2
B + 4.1
1.00mm for 9, 15, 21, 25 way; otherwise 0.80mm
1.84mm for 9, 15, 21, 25 way; otherwise 3.00mm
B
1.00
0.70
1.30
6.00
3.40
1.95
C
5.60
MALE
1.00
A
B
D
E
4.20
0.40
B+1
3.30
E
Ø1.30
B+1
Ø1.20
C
C
5.60
D
Recommended PC Board Pattern
HOW TO ORDER
M40 - 6 X 0 XX XX X
SERIES CODE
GENDER
0
2
Male
Female
PACKAGING
Blank
R
Loose
Tape & Reeled
FINISH
46
Tin
TOTAL NO. OF CONTACTS
09, 15, 21, 25, 31, 41, 51
All dimensions in mm.
www.harwin.com
147
