December 1995, Rev. E
NO R
Data
e
r T
Sheet
ww.
ct ou RSIL or w
ta
con -INTE
1-888
EL2072
FN7033
730MHz Closed Loop Buffer
The EL2072 is a wide bandwidth, fast
settling monolithic buffer built using an
advanced complementary bipolar
process. This buffer is closed loop to achieve lower output
impedance and higher gain accuracy. Designed for closed-
loop unity gain, the EL2072 has a 730MHz -3dB bandwidth
and 5ns settling to 0.2% while consuming only 15mA of
supply current.
The EL2072 is an obvious high-performance solution for
video distribution and line-driving applications. With low
15mA supply current and a 70mA output drive, performance
in these areas is assured.
The EL2072's settling to 0.2% in 5ns, low distortion, and
ability to drive capacitive loads make it an ideal flash A/D
driver. The wide 730MHz bandwidth and extremely linear
phase allow unmatched signal fidelity.
The EL2072 can be used inside an amplifier loop or PLL as
its wide bandwidth and fast rise time have minimal effect on
loop dynamics.
Elantec products and facilities comply with MIL-I-45028A,
and other applicable quality specifications. For information
on Elantec's processing, see Elantec document QRA-1:
Elantec's Processing, Monolithic Integrated Circuits.
Features
• 730MHz -3dB bandwidth (0.5V
PP
)
• 5ns settling to 0.2%
• V
S
= ±5V @ 15mA
• Low distortion: HD2, HD3 of -65dBc at 20MHz
• Overload/short-circuit protected
• Closed-loop, unity gain
• Low cost
• Direct replacement for CLC110
Applications
• Video buffer
• Video distribution
• HDTV buffer
• High-speed A/D buffer
• Photodiode, CCD preamps
• IF processors
• High-speed communications
Ordering Information
PART
NUMBER
EL2072CN
TEMP.
RANGE
-40°C to +85°C
-40°C to +85°C
PACKAGE
8-Pin PDIP
8-Pin SO
PKG. NO.
MDP0031
MDP0027
Pinout
EL2072
(8-PIN PDIP SO)
TOP VIEW
EL2072CS
Manufactured under U.S. Patent No. 4,893,091
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2003. All Rights Reserved. Elantec is a registered trademark of Elantec Semiconductor, Inc.
All other trademarks mentioned are the property of their respective owners.
EL2072
Absolute Maximum Ratings
(T
A
= 25°C)
Supply Voltage (V
S
) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±7V
Output Current
Output is short-circuit protected to ground, however, maximum reliability is
obtained if I
OUT
does not exceed 70mA.
Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±V
S
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . .-40°C to +85°C
Junction Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175°C
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . .-60°C to +150°C
Thermal Resistance.
. . . . . . . . . . . . . . . . . . . . . . . .θ
JA
= 95°C/W PDIP
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . θ
JA
= 175°C/W SO
Note: See EL2071/EL2171 for Thermal Impedance curves.
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
IMPORTANT NOTE: All parameters having Min/Max specifications are guaranteed. Typical values are for information purposes only. Unless otherwise noted, all tests
are at the specified temperature and are pulsed tests, therefore: T
J
= T
C
= T
A
DC Electrical Specifications
PARAMETER
V
OS
Output Offset Voltage
V
S
= ±5V, R
L
= 100Ω, R
S
= 50Ω unless otherwise specified
TEST CONDITIONS
TEMP
25°C
T
MIN
T
MAX
MIN
TYP
2.0
MAX
8.0
16.0
13.0
20.0
20.0
10.0
50.0
100.0
50.0
100.0
200.0
200.0
0.96
0.95
0.2
0.4
0.8
0.3
45.0
65.0
15.0
100.0
50.0
200.0
1.6
2.2
2.5
2.0
3.0
3.5
50.0
45.0
±3.2
±3.0
±4.0
70.0
160.0
20.0
0.98
300.0
700.0
V/V
V/V
%F.S.
%F.S.
%F.S.
dB
mA
kΩ
kΩ
kΩ
pF
pF
Ω
Ω
mA
mA
V
V
µA
µA
nA/°C
UNITS
mV
mV
mV
µV/°C
DESCRIPTION
TCV
OS
Average Offset Voltage Drift
25°C - T
MAX
25°C - T
MIN
I
B
Input Bias Current
25°C, T
MAX
T
MIN
TCI
B
Average Input Bias Current Drift
25°C - T
MAX
25°C - T
MIN
A
V
Small Signal Gain
R
L
= 100Ω
25°C
T
MIN
, T
MAX
ILIN
Integral End Point linearity
±2V F.S.
25°C
T
MIN
T
MAX
PSRR
I
S
R
IN
Power Supply Rejection Ratio
Supply Current—Quiescent
Input Resistance
No Load
All
All
25°C
T
MIN
T
MAX
C
IN
Input Capacitance
25°C
T
MIN
, T
MAX
R
OUT
Output Impedance (DC)
25°C
T
MIN
, T
MAX
I
OUT
Output Current
25°C, T
MAX
T
MIN
V
OUT
Output Voltage Swing
R
L
= 100Ω
25°C, T
MAX
T
MIN
2
