V15
︳
Features
* Universal Input Range 90~264VAC
* Meets EN55022 Class B and
CISPR/FCC Class B
* Continuous Short Circuit Protection
* Over Voltage Protection
* Meet CEC & ErP Level V
(Output Cable Length
≦
1800mm)
(TRG70A120: Output Cable Length
≦
720mm 16AWG)
(TRG70A150: Output Cable Length
≦
1220mm 16AWG)
TRG70 SERIES
70W SWITCHING
ADAPTER
Ordering information
TRG70AXXX- XX
Model No.
DC Plug Type
X
OVP
E: WITH OVP
XX
DC Cable Length and Type
01: 720mm
02: 1220mm
03: 1800mm
11: 720mm with Ferrite Core
12:1220mm with Ferrite Core
13:1800mm with Ferrite Core
*18AWG/UL1185
MODEL
OUTPUT
VOLTAGE
12V
15V
18V
19V
24V
48V
OUTPUT
CURRENT
5.5A
4.6A
3.9A
3.7A
3.0A
1.5A
RIPPLE &
NOISE
NOTE 2
1%
1%
1%
1%
1%
1%
VOLTAGE
ACCURACY
NOTE 1
±2%
±2%
±2%
±2%
±2%
±2%
LINE
REGULATION
NOTE 3
±1%
±1%
±1%
±1%
±1%
±1%
LOAD
REGULATION
NOTE 4
±5%
±3%
±2%
±2%
±2%
±2%
% EFF. (Typ.)
NOTE 5
87%
87%
86%
87%
89%
90%
TRG70A120
TRG70A150
TRG70A180
TRG70A190
TRG70A240
TRG70A480
Specifications are subject to change without notice.
1
V15
Specifications
INPUT SPECIFICATIONS:
Voltage …...………........….................................................... 90~264Vac
Frequency ………………………………………….……………..... 50 to 60Hz
Inrush Current ………………............. Cold Start @25℃ 80A max. @240Vac
Conducted EMI ………………………….………………CISPR/FCC Class B
Leakage Current …………………………………………….…… 3.5mA max.
TRG70 Series Derating Curve
100%
Rated Load(%)
75%
50%
25%
0%
0
10
20
30
40
Ambient Temperature(
o
C)
50
60
20LFM(Natural Convection)
OUTPUT SPECIFICATIONS:
Holdup Time
Short Circuit
Over Voltage
Temperature
……………………………………………… 8ms typ. @115Vac
Protection ………………………….……………… Continuous
Protection ……………...........................................….....… Yes
Coefficient ……………………............................… ±0.05%/℃
GENERAL SPECIFICATIONS:
Isolation ………………………………………… Input to output = 4,242VDC
Operating Temperature .............................. 0 ~ 60℃ (see derating curve)
Storage Temperature ……………………………...….......……........ -20~85℃
Humidity …………………..….......……........ 93% RH max. Non condensing
Cooling …………………………………..……………….. Natural Convection
Switching Frequency …………………………………………… 60KHz Typical
MTBF ……… MIL-HDBK-217F, GB, at 25℃/115VAC ………. 200K hrs min.
Altitude …………………………………………………………………… 2000m
Dimensions ……..…. 5.197x2.283x1.201 inches (132.00x58.00x30.50 mm)
Weight ……………………………………………………… 345g(0.76 Pounds)
AC Inlet ……………….…………………………………...……… IEC320/C14
NOTE:
1. Voltage accuracy at 60% full load.
2. Add a 0.1uF ceramic capacitor and a 10uF E.L. capacitor to output for
Ripple & Noise measurement @20MHz BW.
3. Line regulation measured from 100Vac to 240Vac, full load.
4. Load regulation measured from 60% to 100% full load and from 60% to
20% full load (60% +/- 40% full load).
5. Typical efficiency at 230VAC and full load at 25℃.
6. ”Various TR Series adapters are PSE certified. PSE certification
alone is not sufficient for importation into Japan. A valid PSE mark
must contain the name of the importer as shown in the example below.
If PSE mark is required, the name of the registered importer must be
supplied to Cincon on order placement. Product labels will not contain
PSE mark if importer name is not supplied. Consult factory or local
represen tative for details”
SAFETY AND EMC:
Emission and lmmunity ………… EN55022 Class B, FCC Part 15 Class B
EN61000-6-3,EN61000-3-2,EN61000-3-3
EN55024, EN61204-3, EN61000-6-1
Safety ………………………………… IEC60950-1, EN60950-1, UL60950-1
Mechanical Specification
All Dimensions are in inches(mm)
Tolerance:Inches:X.XXX±0.02
Millimeters:X.XX±0.5
LED
IEC320/C14
DC Plug type: V+ ─●)─ V-
DC Plug :Right Angle(ψ5.5／ψ2.1) L12mm
18AWG／1800mm
Typical at 25˚C, nominal line and 75% load, unless otherwise Specified
2
Power technology
