10W DC-DC Regulated Dual Output Converter
DKE10
series
SPECIFICATION
ORDER NO.
DC VOLTAGE
CURRENT RANGE
RATED POWER
OUTPUT
LINE REGULATION
LOAD REGULATION
VOLTAGE ACCURACY
Note.3
¡½
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡Ó
¡Ó
100 ~
¡Ó
1000mA
10W
Features :
2:1 wide input range
4:1 wide input range(option)
1000VDC I/O isolation
3000VDC I/O isolation(option)
Built-in EMI filter
Protections: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% burn-in test
Low cost / High reliability
Approvals: FCC / CE
2 years warranty
DKE10A- DKE10B- DKE10C- DKE10A- DKE10B- DKE10C- DKE10A- DKE10B- DKE10C- DKE10A- DKE10B- DKE10C-
05
05
05
12
12
12
15
15
15
24
24
24
5V
12V
15V
24V
¡Ó
¡Ó
42 ~
¡Ó
420mA
60mVp-p
¡Ó
¡Ó
33.3 ~
¡Ó
333mA
60mVp-p
¡Ó
¡Ó
21 ~
¡Ó
210mA
80mVp-p
RIPPLE & NOISE (max.)
Note.2
50mVp-p
¡Ó
0.3%
Note.4
¡Ó
0.5%
¡Ó
2.0%
SWITCHING FREQUENCY
VOLTAGE RANGE
EFFICIENCY (Typ.)
INPUT
DC CURRENT
FILTER
PROTECTION
OVER CURRENT
PROTECTION
(Note. 5)
250KHz min.
A: 9 ~ 18VDC B: 18 ~ 36VDC C: 36 ~ 72VDC
81%
78%
80%
82%
80%
Full load
No load
A: 1100mA B: 530mA
A: 30mA
B: 16mA
C: 270mA
C: 8mA
83%
80%
80%
82%
82%
81%
85%
Pi network
Fuse recommended
160% ~ 250% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
All output equipped with short circuit
Protection type : Hiccup mode, recovers automatically after fault condition is removed
-25 ~ +71
SHORT CIRCUIT
WORKING TEMP.
WORKING HUMIDITY
¢J
(Refer to output load derating curve)
¢J
20% ~ 90% RH non-condensing
-25 ~ +105 , 10 ~ 95% RH
0.03% / (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
WITHSTAND VOLTAGE
SAFETY & ISOLATION RESISTANCE
EMC
EMC EMISSION
EMC IMMUNITY
MTBF
DIMENSION
WEIGHT
¡Ó
¢J
¢J
I/P-O/P:1KVDC
I/P-O/P: 100M Ohms / 500VDC / 25 / 70% RH
¢J
Compliance to EN55022 Class B, FCC part 15 Class B
Compliance to EN61000-4-2,3,4,5,6,8, light industry level, criteria A
500Khrs min. MIL-HDBK-217F(25 )
¢J
OTHERS
50.8*25.4*11.2mm or 2"*1"*0.44" inch (L*W*H)
32g
Mechanical Specification
Unit: mm
50.8
15.3
20.3
11.27
Pin Configuration
Derating Curve
Pin No.
1
2
3
4
5
Output
+ Vi n
- Vi n
+ Vo u t
COM
- Vo u t
100
2.5
25.4
1
2
BOTTOM VIEW
4
5
10.2 10.2
3
LOAD (%)
5.1 10.1
80
1.0
£r
+ 0.2/-0.1
2.5
5.8
-25
0
25
50 60 71
Ta (
NOTE
1.All parameters are specified at normal input, rated load, 25 70% RH ambient.
2.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
3.Line regulation is measured from low line to high line at rated load.
4.Load regulation is measured from 10% to 100% rated load.
5.Please prevent the converter from operating in overload or short circuit condition for more than 30 seconds.
¢J
)
100
¢J
File Name:DKE10-SPEC 2012-07-18
