Digital Phosphor Oscilloscopes
TDS7000B Series
Features & Benefits
Up to 7.25 GHz True
Analog Bandwidth and
Down to 43 ps Rise Time
(20% to 80%)
>400,000 wfms/s Waveform
Capture Rate, Powered by
Exclusive DPX
®
Acquisition
Technology
20 GS/s Maximum Real-time
Sample Rate
Exceptional Delta-time
Accuracy for High-confidence
in Critical Timing Measurements
Powerful Triggering Features
for Fast Detection of
Relevant Faults
Communications Mask
Testing Up to 4.25 Gb/s Rates
Clock Recovery from Serial
Data Streams up to 3.125 Gb/s
Up to 64 MB Record Length
with MultiView Zoom
TM
for
Quick Navigation of Long
Records
Superior Measurement Fidelity, Unrivaled Analysis,
Uncompromised Usability
The TDS7000B Series’ unique combination
of superior measurement fidelity, unrivaled
analysis, and uncompromised usability
makes it the ultimate test machine to sim-
plify and speed the design of high-speed,
complex systems. This family offers the
industry’s best solution to the challenging
signal integrity issues faced by designers
verifying, characterizing and debugging
sophisticated electronic designs.
They deliver up to 7.25 GHz (typical) true
analog bandwidth, down to 43 ps rise time
(20% to 80%) and 20 GS/s maximum real-
time sample rate to capture critical events
with fine detail. Exclusive DPX acquisition
technology enables waveform capture rates
up to 400,000 wfms/s to quickly find rare
glitches in seconds or minutes, instead of
hours or days. Innovative software solutions
deliver domain expertise for advanced
analysis and compliance testing, while the
OpenChoice
®
architecture enables users to
integrate their expertise through the ability
to easily write custom programs or utilize
popular commercial software. The intuitive
graphical user interface delivers sophisti-
cated capability to advanced users without
intimidating occasional users.
®
TekConnect
®
Interface for
High Fidelity Connection
Classic Direct Controls,
Touch-sensitive Display, or
Mouse Navigation
OpenChoice
®
with Windows
2000 Delivers Built-in
Networking and Analysis
XGA 1024x768 display
Applications
Signal Integrity, Jitter and
Timing Analysis
Verification, Debug and
Characterization of
Sophisticated Designs
Design Development and
Compliance Testing of Serial
Data Streams Up to
4.25 Gb/s Rates
Debug of Telecom, Datacom
and Storage Area Network
Equipment Designs and
High-speed Backplanes
Spectral Analysis
Investigation of Transient
Phenomena
1
Oscilloscopes
•
www.tektronix.com/tds7000B
Digital Phosphor Oscilloscopes
TDS7000B Series
Characteristics
Ve r t i c a l S y s t e m
TDS7054
TDS7104
TDS7154B
TDS7254B
TDS7404B
TD
Input Channels
Hardware Analog Bandwidth (–3 dB)
4
500 MHz
4
1 GHz
4
1.5 GHz
*1
4
2.5 GHz
*1
4
4 GHz
*1
7
(typi
g
Rise Time 10% to 90% (typical)
Rise Time 20% to 80% (typical)
DC Gain Accuracy
Hardware Bandwidth Limits
Input Coupling
Input Impedance
Input Sensitivity, 1 MΩ
Input Sensitivity, 50
Ω
Vertical Resolution
Max Input Voltage, 1 MΩ
800 ps
1%
400 ps
200 ps
135 ps
130 ps
83 ps
±(2% +
(2% x offset))
100 ps
72 ps
±
(2%
250 MHz or 20 MHz
AC, DC, GND
1 MΩ ±0.5% or 50
Ω
±1%
1 mV/div to 10 V/div
1 mV/div to 1 V/div
8-Bit (>11-Bit with averaging)
±150 V CAT I Derate at
20 dB/decade to
9 V
RMS
above 200 kHz
5 V
RMS
with peaks less than
±30 Volts
1 mV/div to 100 mV/div: ±1 V
101 mV/div to 1 V/div: ±10 V
1.01 V/div to 10 V/div: ±100 V
≥100:1
at 100 MHz and
≥30:1
at the rated bandwidth
Requires TCA-1 MEG
DC, GND
50
Ω
±2.5%
—
2 mV/div to 1 V/div
8-Bit (>11-Bit with averaging)
—
Max Input Voltage, 50
Ω
<1 V
RMS
for <100 mV/div,
<5 V
RMS
for
≥100
mV/div settings
Also determined by TekConnect
®
accessory
2 mV to 50 mV/div: ±0.5 V
50.5 mV to 99.5 mV: ±0.25 V
100 mV to 500 mV: ±5 V
505 mV to 1 V/div: ±2.5 V
≥80:1
at 1.5 GHz and
≥15:1
at rated bandwidth
Offset Range
Channel-to-Channel Isolation
Any Two Channels at Equal
Vertical Scale Settings
*1
At
≥10
mV/div.
Note:
Typical system bandwidth of TDS7404B with P7240: 4 GHz.
Note:
Typical system bandwidth of TDS7404B with P7330: 3.5 GHz.
Note:
Typical system bandwidth of TDS7704B with P7260: 6 GHz
Note:
Typical system bandwidth of TDS7704B with P7350: 5 GHz.
2
Oscilloscopes
•
www.tektronix.com/tds7000B
Digital Phosphor Oscilloscopes
TDS7000B Series
Ti m e B a s e S y s t e m
TDS7054/TDS7104
TDS7154B/TDS7254B/TDS7404B/TDS7704B
Time Base Range
Time Base Delay Time Range
Channel-to-channel Deskew Range
Delta Time Measurement Accuracy
Trigger Jitter (RMS)
200 ps/div to 40 s/div
16 ns to 250 s
±25 ns
±((0.06/sample rate) +
(15 ppm x reading)) RMS
8 ps
RMS
(typical)
50 ps to 10 s/div
5 ns to 250 s
±75 ns
±((0.06/sample rate) +
(2.5 ppm x reading)) RMS
2 ps
RMS
(typical) (7254B/7154B)
1.5 ps
RMS
(typical) (7404B)
1.2 ps
RMS
(typical) (7704B)
2.5 ppm over any
≥100
ms interval
Long Term Sample Rate and Delay
Time Accuracy
±15 ppm over
≥1
ms interval
Acquisition System
TDS7054
Real-time Sample Rates
TDS7104
TDS7154B/ TDS7254B/ TDS7404B/ TDS7704B
1 channel (max)
2 channels (max)
3-4 channels (max)
Equivalent Time Sample Rate (max)
Maximum Record Length per Channel
with Standard Memory
With Memory Opt. 2M
With Memory Opt. 3M
With Memory Opt. 4M
With Memory Opt. 5M
5 GS/s
5 GS/s
2.5 GS/s
250 GS/s
10 GS/s
5 GS/s
2.5 GS/s
250 GS/s
20 GS/s
10 GS/s
5 GS/s
1 TS/s
4 Mb (1-CH.), 2 Mb (2-CH.), 1 Mb (4-CH.)
2 Mb (1-CH.), 1 Mb (2-CH.),
500 Kb (4-CH.)
8 Mb (1-CH.), 4 Mb (2-CH.), 2 Mb (4-CH.)
16 Mb (1-CH.), 8 Mb (2-CH.), 4 Mb (4-CH.)
32 Mb (1-CH.), 16 Mb (2-CH.), 8 Mb (4-CH.)
64 Mb (1-CH.), 32 Mb (2-CH.), 16 Mb (4-CH.)
Oscilloscopes
•
www.tektronix.com/tds7000B
3
Digital Phosphor Oscilloscopes
TDS7000B Series
Maximum Duration at Highest Real-time Resolution (1-CH)
TDS7054
TDS7104
TDS7154B/TDS7254B/TDS7404B/TDS7704
Time Resolution (Single-shot)
Max Duration with Standard Memory
Max Duration with Opt. 2M
Max Duration with Opt. 3M
Max Duration with Opt. 4M
Max Duration with Opt. 5M
200 ps (5 GS/s)
400 µs
1.6 ms
3.2 ms
100 ps (10 GS/s)
200 µs
800 µs
1.6 ms
50 ps (20 GS/s)
200 µs
400 µs
800 µs
1.6 ms
3.2 ms
Acquisition Modes
TDS7054/TDS7104
TDS7154B/TDS7254B/TDS7404B/TDS7704
FastAcq Acquisition
Maximum FastAcq Waveform
Capture Rate
Waveform Database
Sample
Peak Detect
Minimum Peak Detect Pulse Width
Averaging
Envelope
Hi-res
FastFrame Acquisition
™
Powered by exclusive DPX
®
acquisition technology, FastAcq optimizes the instrument
for analysis of dynamic signals and capture of infrequent events
>200,000 wfms/sec
>400,000 wfms/sec
Accumulate Waveform Database providing three-dimensional array of amplitude, time and coun
Acquire sampled values
Captures narrow glitches at all real-time sampling rates
≤1
ns
400 ps
From 2 to 10,000 waveforms included in average
From 2 to 2x10
9
waveforms included in min-max envelope
Real-time boxcar averaging reduces random noise and increases resolution
Acquisition memory divided into segments; maximum trigger rate >265,000 waveforms per seco
Time of arrival recorded with each event
4
Oscilloscopes
•
www.tektronix.com/tds7000B
Digital Phosphor Oscilloscopes
TDS7000B Series
P i n p o i n t
™
Tr i g g e r S y s t e m
TDS7054
Sensitivity
TDS7104
TDS7154B/TDS7254B/TDS7404B/TDS7704B
Internal DC Coupled
0.35 div DC
to 50 MHz
increasing to
1 div at
500 MHz
400 mV from DC
to 50 MHz
increasing to
750 mV at
100 MHz
0.35 div DC
to 50 MHz
increasing to
1 div at
1 GHz
250 mV from DC
to 50 MHz
increasing to
500 mV at
100 MHz
0.5 div DC to 50 MHz increasing to 1.5 div at 3 GHz
TDS7404B/TDS7704B: 2.7 div at 4 GHz (typical)
External (Auxiliary Input)
150 mV from DC to 50 MHz increasing
to 500 mV at 2.5 GHz
Main Trigger Modes
Trigger Sequences
Trigger Characteristics
Auto, Normal and Single
Main, Delayed by Time, Delayed by Events. All sequences can include separate horizontal delay
after the trigger event to position the acquisition window in time
Standard Trigger Types
Edge, Glitch, Runt, Width, Transition
Time, Timeout, Pattern, State,
Setup/Hold
A Event: All above types
Delayed B Event: Edge
Edge, Glitch, Runt, Width, Transition Time, Timeout, Pattern,
State, Setup/Hold, Window – all except Edge,
Pattern and State can be logic qualified by up to two channels
A Event and Delayed B Event: All above types
Reset: Reset if B Event does not occur within specified time, before
specified number of events, or before specified State changes
A Event and Delayed B Event
Trigger Types
Communications-related Triggers
(requires Option SM)
Serial Pattern Trigger
(requires Option ST)
Trigger Level Range
Support for AMI, HDB3, BnZS, CMI, MLT3 and NRZ encoded communications signals.
Select among isolated positive or negative one, zero pulse form or eye patterns as applicable to standard
64-Bit serial word recognizer, bits specified in binary
(high, low, don’t care) or hex format.
Trigger on NRZ-encoded data up to 1.25 GBaud
Internal
External (Auxiliary In)
Line
Trigger Coupling
Trigger Holdoff Range
±8 V
±12 divisions from center of screen
±5 V
fixed at 0 V
DC, AC (attenuates <60 Hz), HF Rej (attenuates >30 kHz), LF Rej (attenuates <80 kHz),
Noise Reject (reduces sensitivity)
250 ns minimum to 12 s maximum
Oscilloscopes
•
www.tektronix.com/tds7000B
5
