NC7WZ32 TinyLogic UHS Dual 2-Input OR Gate
April 2000
Revised January 2005
NC7WZ32
TinyLogic
UHS Dual 2-Input OR Gate
General Description
The NC7WZ32 is a dual 2-Input OR Gate from Fairchild’s
Ultra High Speed Series of TinyLogic
. The device is fabri-
cated with advanced CMOS technology to achieve ultra
high speed with high output drive while maintaining low
static power dissipation over a very broad V
CC
operating
range. The device is specified to operate over the 1.65V to
5.5V V
CC
range. The inputs and output are high impedance
when V
CC
is 0V. Inputs tolerate voltages up to 7V indepen-
dent of V
CC
operating voltage.
Features
s
Space saving US8 surface mount package
s
MicroPak
Pb-Free leadless package
s
Ultra high speed t
PD
2.4 ns Typ into 50 pF at 5V V
CC
s
High output drive
±
24 mA at 3V V
CC
s
Broad V
CC
operating range 1.65V to 5.5V
s
Matches the performance of LCX when operated at
3.3V V
CC
s
Power down high impedance inputs/output
s
Overvoltage tolerant inputs facilitate 5V to 3V translation
