DER-836 - 30W USB PD 3.0 power supply with 3.3V–16V PPS output using InnoSwitch3-PD PowiGaN (INN3878C-H804)

DER-836 - 30 W USB PD 3.0 Power Supply with 3.3 V–16 V PPS Output Using InnoSwitch3-PD PowiGaN (INN3878C-H804)

Overview

30 W USB PD 3.0 Power Supply with 3.3 V–16 V PPS Output Using InnoSwitch3-PD PowiGaN (INN3878C-H804)

Uses InnoSwitch3-PD – off-line QR Flyback Switcher IC with Integrated USB Type-C and USB PD Controller, Integrated High-Voltage Switch, Synchronous Rectification and FluxLink feedback
Integrated USB Type-C and USB PD Controller reduces footprint, no external microcontroller required
Input - 90 VAC – 265 VAC
Variable output - 5 V / 3 A, 9 V / 3 A, 12V / 2.5A 15 V / 2 A, 20 V / 1.5 A, 3.3 V – 11 V / 3 A PPS (30 W Power-limited) Output, or 3.3 V – 16V / 2 A PPS
