[Guangdong University of Technology] Simple transistor amplifier

Overview

Implemented the following functions 1. Basic requirements

(1) The amplifier can output a sinusoidal voltage uo without obvious distortion.

(2) Measure the output resistance.

(3) Draw the waveform diagram.

(4) Display the gain of the amplifier.

2. Play part

(1) It can output the distorted voltage at the top and draw the waveform diagram.

(2) It can output the voltage with bottom distortion and draw the waveform diagram.

(3) When the amplifier outputs distortion-free voltage and two distortion voltages, the peak-to-peak value is not less than 2V.

(4) The measurement shows the approximate value of the distortion-free voltage and the "total harmonic distortion" of the two distortion voltages.

Design Files
