Lichuang EDA has designed two very practical circuit test boards, which are divided into plug-in circuit test boards and chip device test boards. This is a patch test board.
You can modify and adjust it according to your own needs, or you can use it directly as a prototype.
The large square of the verification board is the floating part used to connect the pins of each device.
