TM4C123G full screen 1.14 inch core board tiva

TM4C123GH6PM core board

Schematic design

PCB design

To facilitate wiring, rotate the MCU 45 degrees and shorten the upper and lower four pads to pass DRC inspection

(In order to delete the silk screen, I disbanded the component symbols, but there is no backup... It is very troublesome to modify it now.)

LCD display animation program

Video to binary bin file code: img_To_gray.m

Video to RGB565 format bin file code: video_to_RGB565bin.m

The code comes from the following link, slightly modified, and follows the original CC 4.0 BY-SA copyright agreement
link: https://blog.csdn.net/howlclat/article/details/65448971

Link: https://blog.csdn.net/qq_36868623/article/details/120419027

Demo video

Bilibili video address: https://www.bilibili.com/video/BV1kg411f7wS?share_source=copy_web
