DER-979 - 100 W in-wall USB socket with selectable output voltage using InnoSwitch4-CZ PowiGaN and ClampZero

DER-979 - 100 W In-Wall USB Outlet with Selectable Output Voltage Using InnoSwitch4-CZ PowiGaN and ClampZero

Overview

100 W compact flyback power supply for in-wall USB sockets or power strips with USB ports using PowiGaN-based InnoSwitch4-CZ (INN4077C-H182) and ClampZero (CPZ1075M) Input: 100-132 VAC via feedback resistor Adjustable selectable output: 5V/6.5A, 9V/6A, 15V/5A, 20V/5A >94.5% Full load efficiency <25 mW System no-load input power is suitable for compact housings with high operating ambient temperatures and a small number of components (< 60)100 W Compact Flyback Power Supply for In-Wall USB Outlets or Power Strips with USB Ports Using PowiGaN-based InnoSwitch4-CZ (INN4077C-H182) and ClampZero (CPZ1075M)Input: 100-132 VACSelectable Output via feedback resistor adjustment: 5V /6.5A, 9V/6A, 15V/5A, 20V/5A>94.5% Full Load Efficiency<25 mW System No-Load Input PowerSuitable for compact enclosures with high operating ambient temperatureLow Component Count (<60)

Blockdiagram
