DER-484 - 300 W forward power supply

DER-484 - 300 W Forward Power Supply

Overview

This engineering report describes a 61 V (nominal), 280 W power supply reference design operating at 90-264 VAC. A 5 V, 4 A backup output is also available. The main output of the power supply is designed with constant voltage/constant current characteristics, suitable for battery charger applications. The design is based on PFS7528H and TFS7707H, and the main preamp operating frequency is 66 kHz.
