LM2596 power supply circuit

Overview

Using an LM2596 5.0 to step down from 24V to 5V, and using an LDO to step down to 3.3V.

PDF_LM2596 power supply circuit.zip

Altium_LM2596 power supply circuit.zip

PADS_LM2596 power supply circuit.zip

BOM_LM2596 Power Supply Circuit.xlsx

94319

AD8099 High-speed op-amp

High-speed amplifier circuit based on AD8099

A high-speed amplifier circuit with 10x gain built using AD8099
has been verified. At 100MHz, it can amplify a 100mV peak-to-peak sine wave to approximately 900mV.
Single-sided routing is convenient for manual PCB fabrication.
Note: The SMA interface should be BWSMA-KE-PO01 (searchable on LCSC).

AD8099 chip introduction: Ultra-low distortion, high speed, 0.95NV/√Hz voltage noise operational amplifier; at a gain of 10, bandwidth up to 550MHz, slew rate up to 1350V/µs.

AD8099 High-Speed Operational Amplifier_2024-06-10.epro

PDF_AD8099 High-Speed Op-Amplifier.zip

Altium_AD8099 high-speed op-amp.zip

PADS_AD8099 High-Speed Operational Amplifier.zip

BOM_AD8099 High-Speed Op-Amplifier.xlsx

94320

Summer Dragonflies

The spring flows silently, its gentle stream cherished; the shade of the trees reflects on the water, loving the soft sunshine. A tiny lotus bud just begins to emerge, and a dragonfly has already alighted on it. Create a summer dragonfly LED light.

petal_20240530_234533.mp4

PDF_Summer Dragonfly.zip

Altium_SummerDragonfly.zip

PADS_Summer Dragonfly.zip

BOM_Summer Dragonfly.xlsx

94321
