TCR3DF25

Among 2 related components, TCR3DF25 have related pdf.

Part Number	Manufacturer	Description	Datasheet
TCR3DF25,LM(CT	Toshiba Semiconductor	LDO Regulator Pos 2.5V 0.3A 5-Pin SMV T/R	Download
TCR3DF25LMCT	Toshiba Semiconductor	LDO Voltage Regulators CMOS point regulator 6V 300mA	Download

TCR3DF25 parameters：

Description

LDO Regulator Pos 2.5V 0.3A 5-Pin SMV T/R

Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Type	LDO
Number of Outputs	1
Polarity	Positive
Accuracy (%)	±1
Output Type	Fixed
Output Voltage (V)	2.5
Maximum Output Current (A)	0.3
Minimum Input Voltage (V)	1.8
Maximum Input Voltage (V)	5.5
Maximum Dropout Voltage @ Current (V)	0.31@300mA
Line Regulation	15mV
Load Regulation	50mV
Maximum Power Dissipation (mW)	580
Special Features	Thermal Protection\|Current Limit
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Packaging	Tape and Reel
Supplier Package	SMV
Pin Count	5
Mounting	Surface Mount
Package Height	1.1
Package Length	2.9
Package Width	1.6
PCB changed	5
Lead Shape	Gull-wing
