ISOMETRIC VIEW
CONTACT HOLES NOT SHOWN,
FOR No OF CONTACTS REFER TO TABLE
Parts No List, Dimensions in mm
ITEM CATALOGUE P/ No OF CONTACT
A
B
DIA C
1
MP-4102-13P
13
38.0
29.4
3.23
2
MP-4102-19P
19
41.0
31.8
3.23
3
MP-4102-25P
25
44.5
34.9
3.73
4
MP-4102-37P
37
50.8
39.7
3.73
5
MP-4102-54P
54
57.0
44.5
4.30
6
MP-4102-85P
85
69.8
55.5
4.30
7 MP-4102-150P
150
69.8
55.5
4.30
Amphenol LOGO & PART No
n
D
B
D
C
DIA D
34.2
37.4
40.9
46.7
53.4
65.5
65.5
E
34.5
34.5
35.7
35.7
38.5
38.5
38.5
DIA F
29.0
32.2
35.3
41.4
47.8
59.0
59.0
4
CHANGE FINISH TO BLACK COATING
CHANGE FINISH NOTES
ADD STAINLESS STEEL WEAR PINS
CHANGE FINISH FROM PLATING TO COATING
CHANGE DIM 56.50 TO 55.50
ADD NOTE (ZONE D3)
C
B
NOTES:
CUSTOMER DRAWING
LINEAR
ANGULAR
X ±
X
~
±
1
X,X ±
X
~
X' ±
30'
X,XX±
X
~
X'X"±
15'
BREAK ALL SHARP EDGES
AND REMOVE ALL BURRS
UNLESS OTHERWISE SPECIFIED
TOLERANCE TO BE
1. MATERIAL AND FINISH: DIE CAST ALUMINUM ALLOY, BLACK FINISH
2. SUPPLIED WITH GOLD PLATED CRIMP PIN CONTACTS
3
2
1
0
REV.
T.N
T.N
L.V
T.N
T.N
BY
17/02/2006
09/09/2005
16/04/2004
18/11/2003
21/08/2003
DATE
8478
8422
8277
8236
----
B
THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY
.
LTD.. NO PART THEREOF MAY BE REPRODUCED AND USED
WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER
FIRST ISSUE
CHANGE DETAILS
CHG/No
A
6
5
CAD FILE:
MATL:
FINISH:
DO NOT SCALE
DIMENSIONS IN MILIMETRES
55010250000214
DRN:
CKD:
SEE NOTE 1
APP'D
:
SEE NOTE 1
THIRD ANGLE
PROJECTION
T.N
DATE:
21/08/2003
TITLE:
DATE:
DATE:
P.M
P.M
20/02/06
20/02/06
4
3
SCALE:
PART No:
PANEL RECP
PLUG WITH
PIN CONTACTS
SIZE:
A4
SEE TABLE
Amphenol Australia Pty.Ltd, 2 Fiveways Blvd, Keysborough, Vic3173
DRAWING NO.
Amphenol
2 /2
A
2
55010250-000-2
