ZB2430
THE FASTEST WAY TO WIRELESS
Based on Texas Intstruments’ leading edge 802.15.4 SoC & Z-Stack™ technology,
the ZB2430 family of wireless modules is one of the most powerful ZigBee™-compliant
solutions in the market today. It provides OEMs with industry-leading 2.4GHz module
performance in low power conservation, ease of integration, range, features,
and functionality.
ZB2430 is ideal for power-restricted or battery-operated applications. Its receive and
power-down performance offer OEMs the lower power consumption of any compa-
rable transceiver module. Since it operates in the 2.4 GHz ISM band, the modules can
be used globally--allowing OEMs to standardize on a single platform. Although the IEEE
802.15.4 (PHY & MAC) and ZigBee stack are industry standards, our flexible approach
allows OEMs to customize a solution specific to application requirements.
With the embedded Z-stack, ZB2430 is aimed squarely at secure, low-power mesh
network applications. Modules are offered as Coordinators, Routers, End Devices or
Commissioners. Network scan, remote configuration, dynamic routing, discovery,
security…all unleash the full power of ZigBee. The Development Kit platform and test
utility allow the OEM to explore the best of ZigBee straight out of the box.
FEATuRES
•
Outstanding power consumption
•
Reliable ZigBee™ mesh architecture
•
2.4GHz ISM band for global applications
•
Temperature sensor
•
Long-range performance
•
Configurable GPIO, ADC
•
Over-the-air download (OAD) firmware
updating capability
AppLIcATIOnS
•
Automated meter reading
•
Irrigation systems
•
Medical devices
•
ePOS
global
solutions:
local
support
USA: +1 800 492.2320
Europe: +44 1628 858 940
Asia: +852 2268 6567
wirelessinfo@lairdtech.com
www.lairdtech.com/wireless
TM
Wireless Module
Innovative
Technology
for a
Connected
World
ZB2430
ZB2430 supports ZigBee’s MESH architecture.
Each system consists of a Coordinator, Router,
Commissioner and optional End Devices.
Parameter
Form Factor
Output Power
Frequency
Outdoor Range
Indoor Range
Receive Sensitivity
Serial Data Rate
RF Baud Rate
Temperature Range
Size
Serial Interface
Power Consumption:
Tx
Rx
Sleep
Antenna Options
Z100S1*
Surface Mount
100mW
2400-2483.5 MHz
4.8 km (ext antenna)
400m
-100 dB typical
Up to 115 bps
250 kbps
-40˚ C to +85˚ C
25.4mm x 39 mm x 3.6 mm
3V TTL
140mA@ 3.3V +18dBm
44mA @ 3.3V
7.6 uA
Integrated 2dBi ceramic
antenna, u.FL connector for
external antenna
FCC/IC
Z040S1*
Surface Mount
40mW
2400-2483.5 MHz
1.6 km (ext antenna)
160m
-100 dB typical
Up to 115 bps
250 kbps
-40˚ C to +85˚ C
25.4mm x 39 mm x 3.6 mm
3V TTL
95mA@ 3.3V +14dBm
30mA @ 3.3V
7.6 uA
Integrated 2dBi ceramic
antenna, u.FL connector for
external antenna
CE
cOORdInATOR
a) One coordinator per network
b)
Scans to find available channel
c) Establishes a network
d) Maintains routing tables
e)
Communicates with any device type
ROuTER
a) Maintains routing tables
b)
Communicates with any device type
c) Extends range of network by routing data
over multiple hops
End dEvIcE
a)
Communicates with any device type
b) Supports sleep modes
c)
Dedicated to parent (Router or Coordinator)
cOmmISSIOnER
a)
One Commissioner per network
b)
Server module for OAD firmware upgrades
c) Required for OAD ability
Approvals*
*for additional country approvals, contact us for more information.
ORdERInG InFORmATIOn
Coordinator
Router
End Device
Commissioner
Coordinator
Router
End Device
Commissioner
Z100S1*FC
Z100S1*FR
Z100S1*FE
Z100S1*FM
Z040S1*FC
Z040S1*FR
Z040S1*FE
Z040S1*FM
Development Kit – External antenna
Development Kit - Integrated antenna
Development Kit – External antenna, CE
Development Kit - Integrated antenna, CE
Development Kit – External antenna OAD
Development Kit - Integrated antenna OAD
Development Kit – External antenna, CE, OAD
Development Kit - Integrated antenna, CE, OAD
SDK-Z100S1UF
SDK-Z100S1AF
SDK-Z040S1UF
SDK-Z040S1AF
SDK-Z100S1UF-M
SDK-Z100S1AF-M
SDK-Z040S1UF-M
SDK-Z040S1AF-M
* = A for integrated antenna; U for u.FL
connector (external antenna)
Development Kit include one Coordinator module, two router modules and two end
devices.
LWS-SPEC-ZB2430 0209
Contact information:
USA: +1 800 492 2320
EUROPE: +44 1628 858 940
ASIA: +852 2268 6567
