FQP4N90C / FQPF4N90C
— N-Channel QFET
®
MOSFET
December
2013
FQP4N90C / FQPF4N90C
N-Channel QFET
®
MOSFET
900
V,
4.0
A,
4.2
Ω
Description
Features
This N-Channel enhancement mode power MOSFET is
produced using Fairchild Semiconductor’s proprietary planar
stripe and DMOS technology. This advanced MOSFET
technology has been especially tailored to reduce on-state
resistance, and to provide superior switching performance
and high avalanche energy strength. These devices are
suitable for switched mode power supplies, active power
factor correction (PFC), and electronic lamp ballasts.
•
4.0
A, 900 V, R
DS(on)
=
4.2
Ω
(Max.) @ V
GS
= 10 V,
I
D
=
2.0
A
• Low Gate Charge (Typ.
17
nC)
• Low Crss (Typ.
5.6
pF)
• 100% Avalanche Tested
D
G
D
S
TO-220
G
D
S
G
TO-220F
S
Absolute Maximum Ratings
Symbol
V
DSS
I
D
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
T
J
, T
STG
T
L
T
C
= 25°C unless otherwise noted.
Parameter
Drain-Source Voltage
- Continuous (T
C
= 25°C)
Drain Current
- Continuous (T
C
= 100°C)
Drain Current
- Pulsed
(Note 1)
FQP4N90C
900
4
2.3
16
FQPF4N90C
4*
2.3 *
16 *
±
30
570
4
14
4.5
Unit
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
°C
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
- Derate above 25°C
Operating and Storage Temperature Range
Maximum
Lead Temperature
for
Soldering,
1/8" from
Case
for 5
Seconds.
(Note 2)
(Note 1)
(Note 1)
(Note 3)
140
1.12
-55 to +150
300
47
0.38
*
Drain current limited by maximum junction temperature.
