Non-Catalog Model
Frequency Mixer
Level 17 (LO Power +17 dBm)
Important Note
This is a non-catalog model and can be manufactured on specific request.
Pricing and delivery information can be supplied upon request.
Please click "Back", and then click "Contact Us" for Applications support.
ELECTRICAL SPECIFICATIONS 50Ω @ +25°C
Parameter
Frequency
LO
(fL to fU)
RF
(fL to fU)
IF
mid band
Total Range
Low Range
Mid Range
Upper Range
Low Range
Mid Range
Upper Range
Min.
0.05
0.05
0
Typ.
GRA-3H
CASE STYLE : D08
Conversion Loss
LO-RF Isolation
4.9
45
30
25
35
30
20
+27.5
55
45
35
45
40
30
+30
+10
Max.
200
200
200
7.0
7.5
LO-IF Isolation
IP3 Input
1 dB Comp. Input Power
Notes:
Low Range = [fL to 10fL]
mid band = [2fL to fU/2]
Units
MHz
MHz
MHz
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
Mid Range = [10fL to fU/2]
Upper Range = [fU/2 to fU]
IP3 : RF Power = 0 dBm @ 200 MHz & 202 MHz , LO Power = +17 dBm @ 180 MHz
MAXIMUM RATINGS
Operating Temperature
Storage Temperature
RF Power
IF Current
PIN CONNECTIONS
LO
RF
IF
GROUND
Electrical Schematics
-55°C to 100°C
-55°C to 100°C
200mW
40mA
1
6
4
2, 3, 5
REV. X1
GRA-3H
060622
Page 1 of 1
