KTA1504
Elektronische Bauelemente
-0.15A , -50V
PNP Plastic Encapsulated Transistor
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
FEATURE
Low Noise
Complementary to KTC3875
Excellent h
FE
Linearity
A
L
3
SOT-23
3
Top View
1
2
C B
1
2
CLASSIFICATION OF h
FE
Product-Rank
Range
Marking Code
K
E
D
KTA1504-O
70~140
ASO
KTA1504-Y
120~240
ASY
KTA1504-GR
200~400
ASG
F
REF.
A
B
C
D
E
F
G
Millimeter
Min.
Max.
2.80
3.04
2.10
2.55
1.20
1.40
0.89
1.15
1.78
2.04
0.30
0.50
H
REF.
G
H
J
K
L
J
Millimeter
Min.
Max.
0.09
0.18
0.45
0.60
0.08
0.177
0.6 REF.
0.89
1.02
PACKAGE INFORMATION
Package
SOT-23
MPQ
3K
Leader Size
7 inch
Collector
3
1
Base
2
Emitter
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C unless otherwise specified)
Parameter
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current - Continuous
Collector Power Dissipation
Thermal Resistance From Junction To Ambient
Junction, Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
R
θ
JA
T
J
, T
STG
Ratings
-50
-50
-5
-150
150
833
150, -55~150
Unit
V
V
V
mA
mW
° /W
C
°
C
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Parameter
Collector to Base Breakdown Voltage
Collector to Emitter Breakdown Voltage
Emitter to Base Breakdown Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
DC Current Gain
Collector to Emitter Saturation Voltage
Transition Frequency
Collector Output Capacitance
http://www.SeCoSGmbH.com/
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE
V
CE(sat)
f
T
C
ob
Min.
-50
-50
-5
-
-
70
-
80
-
Typ.
-
-
-
-
-
-
-
-
-
Max.
-
-
-
-0.1
-0.1
400
-0.3
-
7
Unit
V
V
V
µA
µA
V
MHz
pF
Test Conditions
I
C
= -100µA, I
E
=0
I
C
= -1mA, I
B
=0
I
E
= -100µA, I
C
=0
V
CB
= -50V, I
E
=0
V
EB
= -5V, I
C
=0
V
CE
= -6V, I
C
= -2mA
I
C
= -100mA, I
B
= -10mA
V
CE
= -10V, I
C
= -1mA
V
CB
= -10V, I
E
=0, f=1MHz
Any changes of specification will not be informed individually.
15-Feb-2012 Rev. A
Page 1 of 1
