EL7202CSZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> EL7202CSZ

EL7202CSZ: DescriptionHigh Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size516KB，11 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Related ProductsFound19parts with similar functions to EL7202CSZ

Download Datasheet Parametric Compare View All

EL7202CSZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	EL7202CSZ	-	-	View	Buy Now

EL7202CSZ Overview

High Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C

EL7202CSZ Parametric

Parameter Name	Attribute value
Brand Name	Intersil
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC
package instruction	SOP, SOP8,.25
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	6 weeks
Samacsys Description	MOSFET Driver High Speed 2A Dual Non-Inv EL7202CSZ, Dual MOSFET Power Driver 4A, Non-Inverting, 4.5 â†’ 15 V, 8-Pin SOIC
high side driver	NO
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	R-PDSO-G8
JESD-609 code	e3
length	4.9022 mm
Humidity sensitivity level	3
Number of functions	2
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Nominal output peak current	2 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP8,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	15 V
Certification status	Not Qualified
Maximum seat height	1.7272 mm
Maximum supply voltage	15 V
Minimum supply voltage	4.5 V
Nominal supply voltage	15 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn) - annealed
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Disconnect time	0.025 µs
connection time	0.025 µs
width	3.9116 mm
Base Number Matches	1

Preview

Download Datasheet

View All

DATASHEET

EL7202, EL7212, EL7222

High Speed, Dual Channel Power MOSFET Drivers

The EL7202, EL7212, EL7222 ICs are matched dual-drivers

that improve the operation of the industry standard DS0026

clock drivers. The Elantec versions are very high speed

drivers capable of delivering peak currents of 2.0 amps into

highly capacitive loads. The high speed performance is

achieved by means of a proprietary “Turbo-Driver” circuit

that speeds up input stages by tapping the wider voltage

swing at the output. Improved speed and drive capability are

enhanced by matched rise and fall delay times. These

matched delays maintain the integrity of input-to-output

pulse-widths to reduce timing errors and clock skew

problems. This improved performance is accompanied by a

10 fold reduction in supply currents over bipolar drivers, yet

without the delay time problems commonly associated with

CMOS devices. Dynamic switching losses are minimized

with non-overlapped drive techniques.

FN7282

Rev.2.01

Feb 18, 2020

Features

• Industry standard driver replacement

• Improved response times

• Matched rise and fall times

• Reduced clock skew

• Low output impedance

• Low input capacitance

• High noise immunity

• Improved clocking rate

• Low supply current

• Wide operating voltage range

• Pb-Free available (RoHS compliant)

Pinouts

EL7212

(8-PIN PDIP, SO)

TOP VIEW

EL7222

(8-PIN PDIP, SO)

TOP VIEW

Applications

• Clock/line drivers

• CCD Drivers

• Ultra-sound transducer drivers

• Power MOSFET drivers

• Switch mode power supplies

• Class D switching amplifiers

INVERTING

DRIVERS

COMPLEMENTARY

DRIVERS

• Ultrasonic and RF generators

• Pulsed circuits

EL7202

(8-PIN PDIP, SO)

TOP VIEW

NON-INVERTING

DRIVERS

Manufactured under U.S. Patent Nos. 5,334,883, #5,341,047

FN7282 Rev.2.01

Feb 18, 2020

Page 1 of 11

EL7202CSZ Related Products

	EL7202CSZ	EL7222CSZ-T13	EL7222CSZ	EL7212CSZ-T13	EL7222CSZ-T7
Description	High Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C	High Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C	High Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C	High Speed, Dual Channel Power MOSFET Drivers; PDIP8, SOIC8; Temp Range: -40° to 85°C	High Speed, Dual Channel Power MOSFET Drivers; SOIC8; Temp Range: -40° to 85°C
Brand Name	Intersil	Intersil	Intersil	Intersil	Intersil
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	SOIC	SOIC	SOIC	PDIP, SOIC	SOIC
package instruction	SOP, SOP8,.25	SOP, SOP8,.25	SOP, SOP8,.25	SOP, SOP8,.25	SOP, SOP8,.25
Contacts	8	8	8	8, 8	8
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
Factory Lead Time	6 weeks	5 weeks	1 week	7 weeks	4 weeks
high side driver	NO	NO	NO	NO	NO
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8
JESD-609 code	e3	e3	e3	e3	e3
length	4.9022 mm	4.9022 mm	4.9022 mm	4.9022 mm	4.9022 mm
Humidity sensitivity level	3	3	3	3	3
Number of functions	2	2	2	2	2
Number of terminals	8	8	8	8	8
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Nominal output peak current	2 A	2 A	2 A	2 A	2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	SOP	SOP	SOP
Encapsulate equivalent code	SOP8,.25	SOP8,.25	SOP8,.25	SOP8,.25	SOP8,.25
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260	260	260
power supply	15 V	15 V	15 V	15 V	15 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.7272 mm	1.7272 mm	1.7272 mm	1.7272 mm	1.7272 mm
Maximum supply voltage	15 V	15 V	15 V	15 V	15 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage	15 V	15 V	15 V	15 V	15 V
surface mount	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Matte Tin (Sn) - annealed	Matte Tin (Sn) - annealed	Matte Tin (Sn) - annealed	Matte Tin (Sn) - annealed	Matte Tin (Sn) - annealed
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	30	40	30	40	40
Disconnect time	0.025 µs	0.025 µs	0.025 µs	0.025 µs	0.025 µs
connection time	0.025 µs	0.025 µs	0.025 µs	0.025 µs	0.025 µs
width	3.9116 mm	3.9116 mm	3.9116 mm	3.9116 mm	3.9116 mm
Base Number Matches	1	1	1	1	1
