CLD-CT1094.004
PRODUCT FAMILY DATA SHEET
Cree
®
5-mm Blue and Green Round LED
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
PRODUCT DESCRIPTION
Round LEDs offer superior light out-
put for excellent readability in sun-
light and dependable performance.
They provide extremely stable light
output over long periods of time.
FEATURES
•
•
Size (mm): 5
Color and Typical Dominant
Wavelength:
Blue (470nm)
Green(527nm)
Luminous Intensity (mcd)
C503B-BAS/BAN:
(4180-23500)
C503B-BCS/BCN:
(2130-12000)
C503B-GAS/GAN:
(16800-90500)
C503B-GCS/GCN:
(5860-32900)
Viewing angle:
C503B-BAS/BAN/GAS/GAN:
15 degree
C503B-BCS/BCN/GCS/GCN:
30 degree
Lead - Free
RoHS Compliant
APPLICATIONS
•
Electronic Signs & Signals
(ESS)
•
•
•
•
•
Motorway Signs
Variable Message Sign (VMS)
Advertising signs
Petrol Signs
Amusement
•
These lamps are made with an ad-
vanced optical-grade epoxy offering
superior high-temperature and high-
moisture-resistance performance in
outdoor signal and sign applications.
•
•
•
WWW.CREE.COM/HB
Copyright © 2013 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and
Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice.
the Cree logo are registered trademarks of Cree, Inc.
Cree, the Cree logo and XLamp are registered trademarks of Cree, Inc.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
www.cree.com/xlamp
Cree 5-mm Round LED
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Items
Symbol
Absolute Maximum Rating
Blue/Green
Forward Current
Peak Forward Current
Reverse Voltage
Power Dissipation
Operation Temperature
Storage Temperature
Lead Soldering Temperature
Note1
Unit
I
F
I
FP
V
R
P
D
T
opr
T
stg
T
sol
30
100
5
120
-40 ~ +95
-40 ~ +100
mA
mA
V
mW
°C
°C
Max. 260°C for 3 sec. max.
(3 mm from the base of the epoxy bulb)
Note:
1. Pulse width ≤0.1 msec, duty ≤1/10.
TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T
A
= 25°C)
Characteristics
Forward Voltage
Reverse Current
Dominant Wavelength
Color
Blue/Green
Blue/Green
Blue
Green
Blue
Luminous Intensity
Green
C503B-BAS/BAN (15 degree)
C503B-BCS/BCN (30 degree)
C503B-GAS/GAN (15 degree)
C503B-GCS/GCN (30 degree)
Symbol
V
F
I
R
λ
D
λ
D
I
V
I
V
I
V
I
V
2θ½
2θ½
Condition
I
F
= 20 mA
V
R
= 5 V
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
Unit
V
μA
nm
nm
mcd
mcd
mcd
mcd
deg
deg
465
520
4180
2130
16800
5860
470
527
11000
4800
38000
20000
15
30
Minimum
Typical
3.2
Maximum
4.0
100
480
535
50% Power Angle
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree, the Cree logo and XLamp are registered trademarks
Copyright ©
of Cree, Inc. 2013 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks of Cree, Inc.
2
Cree 5-mm Round LED
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
INTENSITY BIN LIMIT (I
F
= 20
mA)
Blue
C503B-BAS/BAN (15 degree)
Bin Code
X0
Y0
Z0
A0
B0
Min.(mcd)
4180
5860
8200
12000
16800
Max.(mcd)
5860
8200
12000
16800
23500
Green
C503B-GAS/GAN (15 degree)
Bin Code
B0
C0
D0
E0
F0
Min.(mcd)
16800
23500
32900
46100
64600
Max.(mcd)
23500
32900
46100
64600
90500
C503B-BCS/BCN (30 degree)
Bin Code
V0
W0
X0
Y0
Z0
Min.(mcd)
2130
3000
4180
5860
8200
Max.(mcd)
3000
4180
5860
8200
12000
C503B-GCS/GCN (30 degree)
Bin Code
Y0
Z0
A0
B0
C0
Min.(mcd)
5860
8200
12000
16800
23500
Max.(mcd)
8200
12000
16800
23500
32900
•
Tolerance of measurement of luminous intensity is ±15%
COLOR BIN LIMIT (I
F
= 20
mA)
Blue
Bin Code
B4
B45
B5
B67
B6
Min.(nm)
465
467.5
470
472.5
475
Max.(nm)
470
472.5
475
477.5
480
Green
Bin Code
G7
G23
G8
G45
G9
Min.(nm)
520
522.5
525
527.5
530
Max.(nm)
525
527.5
530
532.5
535
•
Tolerance of measurement of dominant wavelength is ±1 nm
Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree, the Cree logo and XLamp are registered trademarks
Copyright ©
of Cree, Inc. 2013 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks of Cree, Inc.
3
Cree 5-mm Round LED
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
ORDER CODE TABLE*
Blue (15 degree)
Color
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Kit Number
C503B-BAS-CX0B0461
C503B-BAS-CY0Z0451
C503B-BAS-CZ0A0451
C503B-BAN-CX0B0461
C503B-BAN-CY0Z0451
C503B-BAN-CZ0A0451
C503B-BAS-CX0B0462
C503B-BAS-CY0Z0452
C503B-BAS-CZ0A0452
C503B-BAN-CX0B0462
C503B-BAN-CY0Z0452
C503B-BAN-CZ0A0452
Viewing
Angle
15
15
15
15
15
15
15
15
15
15
15
15
Luminous Intensity (mcd)
Min.
4180
5860
8200
4180
5860
8200
4180
5860
8200
4180
5860
8200
Max.
23500
12000
16800
23500
12000
16800
23500
12000
16800
23500
12000
16800
Color
Bin
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
Dominant Wavelength
Min.
(nm)
465
465
465
465
465
465
465
465
465
465
465
465
Color
Bin
B6
B5
B5
B6
B5
B5
B6
B5
B5
B6
B5
B5
Max.
(nm)
480
475
475
480
475
475
480
475
475
480
475
475
Package
Bulk
Bulk
Bulk
Bulk
Bulk
Bulk
Ammo
Ammo
Ammo
Ammo
Ammo
Ammo
Standoff
Yes
Yes
Yes
No
No
No
Yes
Yes
Yes
No
No
No
Blue (30 degree)
Color
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Kit Number
C503B-BCS-CV0Z0461
C503B-BCS-CW0X0451
C503B-BCS-CX0Y0451
C503B-BCN-CV0Z0461
C503B-BCN-CW0X0451
C503B-BCN-CX0Y0451
C503B-BCS-CV0Z0462
C503B-BCS-CW0X0452
C503B-BCS-CX0Y0452
C503B-BCN-CV0Z0462
C503B-BCN-CW0X0452
C503B-BCN-CX0Y0452
Viewing
Angle
30
30
30
30
30
30
30
30
30
30
30
30
Luminous Intensity (mcd)
Min.
2130
3000
4180
2130
3000
4180
2130
3000
4180
2130
3000
4180
Max.
12000
5860
8200
12000
5860
8200
12000
5860
8200
12000
5860
8200
Color
Bin
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
B4
Dominant Wavelength
Min.
(nm)
465
465
465
465
465
465
465
465
465
465
465
465
Color
Bin
B6
B5
B5
B6
B5
B5
B6
B5
B5
B6
B5
B5
Max.
(nm)
480
475
475
480
475
475
480
475
475
480
475
475
Package
Bulk
Bulk
Bulk
Bulk
Bulk
Bulk
Ammo
Ammo
Ammo
Ammo
Ammo
Ammo
Standoff
Yes
Yes
Yes
No
No
No
Yes
Yes
Yes
No
No
No
Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree, the Cree logo and XLamp are registered trademarks
Copyright ©
of Cree, Inc. 2013 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks of Cree, Inc.
4
Cree 5-mm Round LED
C503B-BAS/BAN/GAS/GAN
C503B-BCS/BCN/GCS/GCN
ORDER CODE TABLE*
Green (15 degree)
Color
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Kit Number
C503B-GAS-CB0F0791
C503B-GAS-CC0D0781
C503B-GAS-CC0D0891
C503B-GAN-CB0F0791
C503B-GAN-CC0D0781
C503B-GAN-CC0D0891
C503B-GAS-CB0F0792
C503B-GAS-CC0D0782
C503B-GAS-CC0D0892
C503B-GAN-CB0F0792
C503B-GAN-CC0D0782
C503B-GAN-CC0D0892
Viewing
Angle
15
15
15
15
15
15
15
15
15
15
15
15
Luminous Intensity (mcd)
Min.
16800
23500
23500
16800
23500
23500
16800
23500
23500
16800
23500
23500
Max.
90500
46100
46100
90500
46100
46100
90500
46100
46100
90500
46100
46100
Color
Bin
G7
G7
G8
G7
G7
G8
G7
G7
G8
G7
G7
G8
Dominant Wavelength
Min.
(nm)
520
520
525
520
520
525
520
520
525
520
520
525
Color
Bin
G9
G8
G9
G9
G8
G9
G9
G8
G9
G9
G8
G9
Max.
(nm)
535
530
535
535
530
535
535
530
535
535
530
535
Package
Bulk
Bulk
Bulk
Bulk
Bulk
Bulk
Ammo
Ammo
Ammo
Ammo
Ammo
Ammo
Standoff
Yes
Yes
Yes
No
No
No
Yes
Yes
Yes
No
No
No
Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree, the Cree logo and XLamp are registered trademarks
Copyright ©
of Cree, Inc. 2013 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks of Cree, Inc.
