HM67-S510

Description
Surface Mount Common Mode Chokes
File Size690KB,5 Pages
ManufacturerETC
Download Datasheet View All

HM67-S510 Overview

Surface Mount Common Mode Chokes

Electrical / Environmental

Surface Mount Common Mode Chokes
Ro
p
H
t
S
losr
lian f
Com
‘LF’ M
ode
Operating Temperature Range
Ambient Temperature, Maximum
Temperature Rise, Maximum
Dielectric Withstanding Voltage
-40°C to +125°C
85°C
40°C
300Vdc
Schematic
Specifications
Common Mode Inductance
@100 kHz - 0.1 V
(1-4 or 2-3)
Inductance Leakage
@100 kHz - 0.1 Vrms
(1-4)
(1)
Typ.
Rated
Current
mA
1000
500
500
500
500
500
500
400
200
200
DCR
(2)
Max.
m
7.2
5.8
9.8
7.2
9.4
8.2
9.4
8.2
9.8
403
Part
Number
HM67-B5R0
HM67-B110
HM67-S250
HM67-B510
HM67-S510
HM67-B471
HM67-B102
(3)
HM67-B222
(3)
HM67-B472
(3)
HM67-10510
Notes:
Terminals
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
1-4, 2-3
µH
µH
5.0 ±30%
11.0 ±30%
25.0 ±30%
51.0 ±30%
51.0 ±30%
470.0 ±30%
1000.0 +50%, -30%
2200.0 +50%, -30%
4700.0 +50%, -30%
51.0 ±30%
0.08
0.10
1.60
1.90
2.80
0.80
0.16
0.16
0.24
2.40
Marking
Code
A
B
C
D
E
F
G
H
I
0510
Figure
1
1
1
1
1
1
1
1
1
2
(1) Leakage inductance is measured with pin 2 & 3 shorted.
(2) DC resistance is measured at 25°C.
(3) Maximum operating temperature is +85°C.
Packaging
Standard:
Embossed Tape & Reel
Reel:
Diameter:
Capacity:
Figure 1 & 2
Figure 1
Figure 2
=
=
=
13” (330.2mm)
400 Units
2000 Units
Ordering Information
Model Series
HM67
B
110
LF
TR13
Winding Type:
B = Bifilar
S /10= Sector
TR13 = Tape & 13” Reel
(Standard)
No code used for tubes
Inductance Code:
First 2 digits are significant.
Last digit denotes the number of trailing zeros.
For values below 10µH, “R” denotes the decimal point.
Lead-Free Option
LF = Lead-Free
(No code used for non lead-free part)
2006 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
www.bitechnologies.com
We reserve the right to change specifications without prior notice
